System And Components
1G-4305 ENGINE ARS/N 7GG374-380; 7GG385-436; 5AJ114-117; 5AJ122-123
Group No: 1G-4305
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4P0844 | 1 ENGINE AR | 1 | |
| 7X8077 | 2 MOUNT (RH) | 1 | |
| 7X8079 | MOUNT (LH) | 1 | |
| 7X8154 | 3 RING | 1 | |
| 5E9870 | 4 BRACKET | 1 | |
| 8T4136 | BOLT (M10X1.5X25-MM) | 1 | |
| 8T4121 | WASHER-HARD (11X21X2.5-MM THK) | 1 | |
| 8T4908 | 5 BOLT (M8X1.25X25-MM) | 4 | |
| 5E9869 | 6 ANGLE | 1 | |
| 4L6454 | 7 BOLT (3/8-16X1-IN) | 8 | |
| 8T4896 | WASHER-HARD (10.2X18.5X2.5-MM THK) | 8 | |
| 1G5679 | 8 CLAMP | 1 | |
| 7X9551 | 9 TUBE (EXHAUST) | 1 | |
| 7C7345 | 10 MUFFLER GP | 1 | |
| 7X8155 | 11 HOSE (UPPER RADIATOR) | 1 | |
| 9M0164 | 12 CLAMP-HOSE | 4 | |
| 7X9660 | 13 GUARD (ALTERNATOR) | 1 | |
| 0869585 | 14 GUARD AS-FAN | 2 | |
| 7X2553 | 15 BOLT (M16X2X40-MM) | 8 | |
| 4M6425 | 16 BOLT (5/16-18X1-IN) | 8 | |
| 5P0598 | 17 CLAMP-HOSE | 1 | |
| 1019606 | 18 RADIATOR & HYD OIL COOLER GP | 1 | |
| 8F5714 | 19 CLAMP | 1 | |
| 8T6869 | 20 BOLT (M8X1.25X60-MM) | 1 | |
| 5C7261 | NUT (M8X1.25-THD) | 1 | |
| 5P4116 | 21 WASHER-HARD (8.8X20.5X2-MM THK) | 8 | |
| 9W9915 | 22 MOUNT AS | 4 | |
| 9W9952 | 23 WASHER (16.75X86X8-MM THK) | 4 | |
| 8T4648 | 24 BOLT (M12X1.75X70-MM) | 1 | |
| 8T4223 | 25 WASHER-HARD (13.5X25.5X3-MM THK) | 6 | |
| 8T6868 | 26 BOLT (M12X1.75X80-MM) | 5 | |
| 7R0262 | 27 HOSE (LOWER RADIATOR) | 1 | |
| 7C0752 | 28 CLAMP | 1 | |
| 4M0310 | 29 PRECLEANER GP | 1 | |
| 1W0613 | 30 INDICATOR AS-AIR FILTER CHANGE (SERVICE) | 1 | |
| 5L3233 | FITTING-CONNECTOR | 1 | |
| 0777254 | 31 CLAMP | 3 | |
| 5E9090 | 32 ELBOW (AIR INTAKE) | 1 | |
| 7X8075 | 33 TUBE | 1 | |
| 5E9095 | 34 ELBOW | 1 | |
| 1047762 | 35 PLATE AS | 1 | |
| 4J8265 | 36 NUT (3/8-16-THD) | 4 | |
| 7W2483 | 37 CLAMP | 2 | |
| 7C9756 | 38 AIR CLEANER GP | 1 | |
| 8T4122 | 39 WASHER-HARD (17X32X3.5-MM THK) | 16 | |
| 7X0353 | 40 BOLT (5/8-11X4.25-IN) | 4 | |
| 9W9953 | 41 SLEEVE | 4 | |
| 4K0367 | 42 NUT-FULL (5/8-11-THD) | 4 | |
| 8T4224 | 43 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 4L6459 | 44 BOLT (3/8-16X2.5-IN) | 1 | |
| 8T4896 | 45 WASHER-HARD (10.2X18.5X2.5-MM THK) | 7 | |
| 4J8265 | 46 NUT (3/8-16-THD) | 4 | |
| 4L6454 | 47 BOLT (3/8-16X1-IN) | 4 | |
| 5E9091 | 48 BAND | 1 | |
| 5E9362 | 49 PIPE-EXHAUST | 1 | |
| 8F5714 | CLAMP | 1 | |
| 7X0818 | BOLT (M8X1.25X45-MM) | 1 | |
| 5C7261 | NUT (M8X1.25-THD) | 1 | |
| 8T4224 | 50 WASHER-HARD (8.8X16X2-MM THK) | 7 | |
| 7T4459 | 51 HOSE AS | 1 | |
| 6V8780 | 52 TEE | 1 | |
| 4J5477 | 53 SEAL-O-RING | 3 | |
| 3J7354 | 54 SEAL-O-RING | 2 | |
| 1019193 | 55 LINES GP-FUEL | 1 | |
| 5E8828 | 56 RETAINER | 1 | |
| 8T5005 | BOLT (M10X1.5X70-MM) | 2 | |
| 8C6855 | 57 BOLT (M14X2X45-MM) | 2 | |
| 9L9009 | WASHER (0.594X1.062X0.188-IN THK) | 2 | |
| 8N5251 | 58 PUMP GP-FUEL PRM & PRIM FILTER | 1 | |
| 4L9337 | 59 BOLT (3/8-16X1.5-IN) | 2 | |
| 6V8647 | 60 CONNECTOR | 1 | |
| 8T4136 | 61 BOLT (M10X1.5X25-MM) | 2 | |
| 8T4121 | 62 WASHER-HARD (11X21X2.5-MM THK) | 7 | |
| 6R3816 | 63 MANIFOLD | 1 | |
| 9Y1751 | 64 STRAP | 1 | |
| 9W3043 | 65 ALTERNATOR GP-CHARGING (24-VOLT, 52-AMPERE) | 1 | |
| 5E9102 | 66 BRACKET | 1 | |
| 9Y0757 | 67 PULLEY GP-FAN DRIVE | 1 | |
| 8T4186 | 68 BOLT (M10X1.5X40-MM) | 2 | |
| 7C3729 | 69 PULLEY-ALTERNATOR | 1 | |
| 2S9779 | 70 V-BELT SET (INCLUDES 2-BELTS) | 1 | |
| 9R5008 | 71 SPACER (11X20X6-MM THK) | 1 | |
| 3P0011 | SPACER (0.44X0.75X0.36-IN THK) | 1 | |
| 8M2770 | 72 CLIP (LOOP) | 1 | |
| 8T4189 | BOLT (M8X1.25X20-MM) | 1 | |
| 8T4908 | 73 BOLT (M8X1.25X25-MM) | 1 | |
| 7X2543 | 74 BOLT (M10X1.5X120-MM) | 1 | |
| 7C5583 | SPACER | 1 | |
| 9Y1267 | 75 WIRE AS | 1 |
