System And Components
419-6722 COOLER GP-OILS/N TRG1-UP
Group No: 419-6722
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1260747 | 1 VALVE GP-BYPASS (COOLER) | 1 | |
| 1352779 | 2 HOSE AS | 1 | |
| 1690908 | 3 MOUNT AS | 4 | |
| 2342453 | 4 HOSE AS | 1 | |
| 3196242 | 5 ELBOW AS | 1 | |
| 6V9004 | ELBOW | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 3332221 | 6 BRACKET AS | 1 | |
| 3709329 | 7 CORE AS-OIL COOLER (STEERING) | 1 | |
| 4392020 | 8 PLATE AS | 1 | |
| 4392022 | 9 PLATE AS | 1 | |
| 2815979 | 10 ELBOW AS | 1 | |
| 6V9007 | ELBOW | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 3196216 | 11 CONNECTOR AS | 2 | |
| 6V8716 | CONNECTOR (STRAIGHT) | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 5P7466 | 12 CLIP (SLOT) | 1 | |
| 5P7467 | 13 CLIP (TAB) | 1 | |
| 5P8112 | 14 GROMMET | 1 | |
| 7X0632 | 15 WASHER-HARD (11X36X6-MM THK) | 4 | |
| 8T4121 | 16 WASHER-HARD (11X21X2.5-MM THK) | 9 | |
| 8T4136 | 17 BOLT (M10X1.5X25-MM) | 6 | |
| 8T4178 | 18 BOLT (M10X1.5X90-MM) | 3 | |
| 8T4185 | 19 BOLT (M10X1.5X50-MM) | 4 |
