System And Components
396-4645 LINES GP-BRAKE COOLINGS/N TRG1-UP
Group No: 396-4645
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3718124 | 1 HOSE (15-CM) | ||
| 8C0620 | 2 PROTECTOR-THREAD | 4 | |
| 4913714 | 3 TUBE AS | 1 | |
| 4913715 | 4 TUBE AS | 1 | |
| 4913716 | 5 TUBE | 1 | |
| 4913717 | 6 PLATE AS | 1 | |
| 4914513 | 7 HOSE AS | 1 | |
| 4914514 | 8 TUBE AS | 1 | |
| 1645567 | 9 COUPLER AS-QUICK DISCONNECT (MALE) | 3 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 1P4584 | 10 FLANGE-HALF | 4 | |
| 1P4585 | 11 FLANGE-HALF | 2 | |
| 2164983 | 12 CLAMP-T BOLT | 4 | |
| 3159840 | 13 ELBOW AS | 3 | |
| 6V8077 | ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3P0653 | 14 SEAL-O-RING | 3 | |
| 6V0852 | 15 CAP-DUST | 3 | |
| 6V8519 | 16 CLAMP-HALF | 8 | |
| 7X0325 | 17 BOLT (1/2-13X2.5-IN) | 9 | |
| 8T0568 | 18 SEAL-O-RING | 2 | |
| 8T4139 | 19 BOLT (M12X1.75X30-MM) | 2 | |
| 8T4140 | 20 BOLT (M16X2X60-MM) | 4 | |
| 8T4194 | 21 BOLT (M12X1.75X50-MM) | 12 | |
| 8T4223 | 22 WASHER-HARD (13.5X25.5X3-MM THK) | 23 | |
| 9X8257 | 23 WASHER (17.5X30X3.5-MM THK) | 4 |
