System And Components
370-5495 CONSOLE GP-OPERATOR -LHS/N CP51-UP
Group No: 370-5495
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0897436 | 1 PIN-SPRING | 1 | |
| 1092356 | 2 PLUG | 6 | |
| 1256084 | 3 NUT-SPEED | 1 | |
| 1957691 | 4 LATCH AS | 1 | |
| 1975681 | 5 SPRING AS-GAS | 1 | |
| 2018754 | 6 BUMPER | 1 | |
| 2018768 | 7 KNOB | 1 | |
| 2319230 | 8 SPACER (8.8X20X8-MM THK) | 1 | |
| 2577621 | 9 COVER AS | 1 | |
| 1092354 | HOUSING | 6 | |
| 2605084 | 10 COVER | 1 | |
| 2605085 | 11 ARMREST GP (LH) | 1 | |
| 2605087 | 12 ROD | 1 | |
| 2724965 | 13 KNOB | 1 | |
| 3705490 | 14 BRACKET AS | 1 | |
| 6C9130 | 15 WASHER (6X18X1-MM THK) | 1 | |
| 8T4224 | 16 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 9X2043 | 17 SCREW-TRUSS HEAD (M6X1X14-MM) | 2 | |
| 9X2044 | 18 SCREW-TRUSS HEAD (M6X1X16-MM) | 1 | |
| 9X2045 | 19 SCREW-TRUSS HEAD (M6X1X20-MM) | 2 | |
| 4578003 | 20 SPRING | 1 | |
| 0897435 | 21 CLEVIS | 1 | |
| 0950758 | 22 SCREW-MACHINE (M6X1X14-MM) | 2 | |
| 1256083 | 23 SCREW-PAN HEAD | 1 | |
| 1313539 | 24 SCREW-FLAT HEAD (M8X1.25X30-MM) | 2 | |
| 1313540 | 25 LOCKNUT (M8X1.25-THD) | 2 | |
| 1313990 | 26 BOLT-CARRIAGE (M8X1.25X30-MM) | 1 | |
| 1388454 | 27 SCREW-TRUSS HEAD (M4X0.7X10-MM) | 1 | |
| 3445673 | 28 NUT (M6X1-THD) | 2 | |
| 5Y0660 | 29 NUT (M6X1-THD) | 3 | |
| 3705496 | 30 COVER AS | 1 | |
| 3705497 | 31 SUPPORT AS | 1 | |
| 3828907 | 32 BRACKET | 1 | |
| 3828908 | 33 LEVER | 1 | |
| 3828909 | 34 LEVER | 1 |
