System And Components
310-3265 MAST GPS/N JCS1-UP
Group No: 310-3265
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5P9982 | 1 FITTING-GREASE | 1 | |
| 6C9011 | 2 RING (BEARING) | 2 | |
| 7X0564 | 3 WASHER-HARD (20X51X3-MM THK) | 2 | |
| 0813119 | 4 SEAL-RUBBER | 2 | |
| 0813772 | 5 LEVER | 1 | |
| 1028703 | 6 PLATE-COVER | 4 | |
| 1240817 | 7 HOSE AS | 2 | |
| 1284119 | 8 CYLINDER AS-TILT | 1 | |
| 1284120 | 9 PUMP AS-HAND | 1 | |
| 2817715 | FILM-INSTRUCTION (CAB LIFT) | 1 | |
| 1387125 | 10 BUMPER | 3 | |
| 1641342 | 11 BOLT-SPECIAL (M10X1.5X28-MM) | 2 | |
| 2337256 | 12 CLEVIS | 1 | |
| 2494738 | 13 SPACER (11X20X32-MM THK) | 2 | |
| 2560548 | 14 HOSE AS | 1 | |
| 2636699 | 15 CONNECTOR-RECEPTACLE (STORAGE) | 1 | |
| 2766146 | 16 SENSOR AS-ANGLE (AS400TC) | 1 | |
| 2775271 | 17 SPRING | 1 | |
| 2939451 | 18 PLATE | 1 | |
| 2951414 | 19 LATCH AS | 1 | |
| 2951415 | 20 BRACKET AS | 1 | |
| 2951416 | 21 PIN AS | 1 | |
| 2951435 | 22 FRAME AS | 1 | |
| 2951439 | 23 MAST AS | 1 | |
| 2957858 | 24 CABLE | 1 | |
| 0965962 | 25 WASHER-HARD (3.4X7X0.8-MM THK) | 4 | |
| 1305300 | 26 CLIP | 1 | |
| 1313540 | 27 LOCKNUT (M8X1.25-THD) | 1 | |
| 1488320 | 28 CONNECTOR AS | 4 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 8C6865 | CONNECTOR | 1 | |
| 1488389 | 29 ELBOW AS | 2 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 7X0492 | ELBOW | 1 | |
| 2066410 | 30 CLAMP-HALF | 8 | |
| 2761326 | 31 BOLT (M10X1.5X55-MM) | 2 | |
| 3E9862 | 32 LOCKNUT (3/4-10-THD) | 2 | |
| 4P7581 | 33 CLIP (LADDER) | 1 | |
| 5C2890 | 34 NUT (M6X1-THD) | 1 | |
| 5C7261 | 35 NUT (M8X1.25-THD) | 3 | |
| 5P8244 | 36 WASHER-HARD (12X22.5X2.5-MM THK) | 4 | |
| 6V9669 | 37 SCREW-MACHINE (M3X0.5X8-MM) | 4 | |
| 7X0370 | 38 BOLT (3/4-10X3.5-IN) | 1 | |
| 7X0575 | 39 WASHER-HARD (10.2X22.5X5-MM THK) | 1 | |
| 7X2440 | 40 BOLT (M20X2.5X320-MM) | 2 | |
| 7X2537 | 41 BOLT (M8X1.25X35-MM) | 4 | |
| 7X2571 | 42 BOLT (M20X2.5X240-MM) | 2 | |
| 7X7729 | 43 WASHER (11X25X3-MM THK) | 8 | |
| 8C6857 | 44 BOLT (3/4-10X2.75-IN) | 1 | |
| 8T3844 | 45 BOLT (M6X1X70-MM) | 2 | |
| 8T4121 | 46 WASHER-HARD (11X21X2.5-MM THK) | 5 | |
| 8T4122 | 47 WASHER-HARD (17X32X3.5-MM THK) | 1 | |
| 8T4123 | 48 WASHER (22X35X3.5-MM THK) | 4 | |
| 8T4136 | 49 BOLT (M10X1.5X25-MM) | 2 | |
| 8T4191 | 50 BOLT (M10X1.5X16-MM) | 1 | |
| 8T4195 | 51 BOLT (M10X1.5X30-MM) | 2 | |
| 8T4197 | 52 BOLT (M8X1.25X40-MM) | 1 | |
| 8T4223 | 53 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 8T4224 | 54 WASHER-HARD (8.8X16X2-MM THK) | 5 | |
| 9X8256 | 55 WASHER (6.6X12X2-MM THK) | 2 | |
| 5P1442 | 56 HOSE (1.2-CM) | ||
| 5P1442 | 56A HOSE (3.5-CM) | ||
| 1772215 | 57 STRAP-DUAL CLAMP | 2 | |
| 3176941 | 58 HARNESS AS-WIRING (RECEIVER) | 1 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 9 | |
| 1261767 | PIN-CONNECTOR (14-GA TO 16-GA) | 9 | |
| 9X4385 | PLUG AS-CONNECTOR (6-PIN) | 1 | |
| 1552260 | KIT-CONNECTING PLUG (3-PIN) | 1 | |
| 8T8737 | PLUG-SEAL | 4 | |
| 1028801 | KIT-RECEPTACLE (12-PIN) | 1 | |
| 1809340 | SOCKET-CONNECTOR (14-GA TO 18-GA) | 2 | |
| 1342540 | RECEPTACLE AS-CONNECTOR (3-PIN) | 1 | |
| 1257874 | TUBE-HEAT SHRINK (5.72-MM DIA)(20-CM) | ||
| 4P7428 | 59 CLIP (LADDER) | 3 | |
| 7K1181 | 60 STRAP-CABLE | 15 | |
| 1458494 | 61 GUARD (47-CM) |
