Assembly
100%

523-6561 AIR CONDITIONER GP -CAB HEATERS/N GCS1-UP

Group No: 523-6561
Part NumberPart NameQty
8T41891 BOLT (M8X1.25X20-MM)5
6V91702 NUT-BULKHEAD (1-14-THD)2
7K11813 STRAP-CABLE5
8T41384 BOLT (M6X1X20-MM)1
8T42245 WASHER-HARD (8.8X16X2-MM THK)7
9S41906 PLUG-O-RING (7/8-14-THD)1
9X20457 SCREW-TRUSS HEAD (M6X1X20-MM)14
9X82568 WASHER (6.6X12X2-MM THK)1
20773539 SCREW (M8X1.25X16-MM)8
261662410 PLUG1
344567411 NUT (M8X1.25-THD)2
376731712 CONNECTOR2
421142113 CAP1
162911214 GROMMET-SPLIT1
383561415 CAP1
475499016 AIR CONDITIONER1
352396617 CLIP (LADDER)1
560515618 BRACKET AS1
6V9632NUT-WELD (M6X1-THD)17
560516119 ENCLOSURE1
560516220 PLATE1
560517021 HOSE2
560517122 HOSE2
560517223 HOSE1
560517424 HOSE1
560518425 WIRING GP-AIR CONDITIONER1
581171126 TEE AS2
6V6609SEAL-O-RING1
5811710TEE1
582238627 SEAL1
582238728 SEAL1
582238829 SEAL1
582956830 BRACKET1
3D620931 GROMMET2
6K818032 GROMMET2
9X203833 WASHER (7X19X2-MM THK)14
9X248834 CLAMP-HOSE8
