System And Components
244-7433 DRAWBAR GPS/N JLF1-UP; WWW1-UP; YYY1-UP
Group No: 244-7433
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3970240 | 1 PIN | 1 | |
| 5P8837 | 2 LOCK PIN | 1 | |
| 2747990 | 3 PLATE-COVER | 1 | |
| 2993902 | 4 DRAWBAR AS | 1 | |
| 2993903 | 5 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 4 | |
| 5P1076 | 6 WASHER-HARD (13.5X30X4-MM THK) | 2 | |
| 7X2576 | 7 BOLT (M24X3X70-MM) | 4 | |
| 8T4121 | 8 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4137 | 9 BOLT (M10X1.5X20-MM) | 7 | |
| 8T4139 | 10 BOLT (M12X1.75X30-MM) | 2 | |
| 8T4167 | 11 WASHER-HARD (26X44X4-MM THK) | 4 | |
| 8T4222 | 12 WASHER-PLATED (11X32X2.5-MM THK) | 3 | |
| 9X2092 | 13 TRIM-EDGE (70-CM) |
