255-4273 DOOR GP-CAB -RHS/N MMM1-1004; RRR1-800

Group No: 255-4273

Part Number	Part Name	Qty
2239818	1 FILM-INSTRUCTION (WINDOW CLEANING, READ OMM)	1
2499061	2 HARNESS AS-SWITCH (DOOR, RH)	1
9W0852	PIN-CONNECTOR (14-GA TO 16-GA)	4
2305008	PLUG AS-CONNECTOR (4-PIN)	1
2647031	SEAL-CONNECTOR	1
9X3402	SOCKET-CONNECTOR (16-GA TO 18-GA)	4
2521862	3 HANDLE AS-PULL	1
2521863	4 GASKET	1
2554256	5 STRIKER AS (RH)	1
2617993	6 MOTOR GP-WINDOW WIPER	1
2621997	7 ARM GP-WINDOW WIPER (RH)	1
3059192	NOZZLE AS-WASHER	1
2669299	8 FRAME AS-DOOR (RH)	1
6V9632	NUT-WELD (M6X1-THD)	6
8T3597	NUT-WELD (M12X1.75-THD)	6
2669303	9 COVER	1
2692887	10 LATCH AS-DOOR (ROTARY)	1
3557354	11 CLEVIS	1
2692892	12 PIN	1
1333234	13 SEAL (425-CM)
2814002	14 PLUG	1
2814136	15 COVER-LATCH (RH)	1
3433798	16 WINDOW	1
2870548	17 STICKER-DOOR SEAL (RH)	1
2906180	18 SPACER (7X11X5-MM THK)	3
1258175	19 BLADE AS-WIPER (450-MM)(DOOR, RH)	1
1313540	20 LOCKNUT (M8X1.25-THD)	2
3236147	22 LINKAGE AS (RH)	1
1028804	23 KIT-RECEPTACLE (4-PIN)	1
9X8267	24 WASHER (6.6X12X2-MM THK)	2
4D0012	25 GROMMET	1
4E1384	26 BUMPER-CONICAL	1
4I4872	27 SPACER (8.6X18X5-MM THK)	2
5C7261	28 NUT (M8X1.25-THD)	1
5P1076	29 WASHER-HARD (13.5X30X4-MM THK)	6
5P8441	30 GROMMET	1
7X2533	32 BOLT (M6X1X35-MM)	2
8C6802	33 SCREW-FLAT HEAD (M6X1X3.72-MM)	4
8T4183	34 BOLT (M12X1.75X40-MM)	6
8T4224	35 WASHER-HARD (8.8X16X2-MM THK)	2
8T6902	36 CLIP	1
9X2042	37 SCREW-TRUSS HEAD (M6X1X12-MM)	3
9X2045	38 SCREW-TRUSS HEAD (M6X1X20-MM)	5
1440195	39 HOSE (26-CM)
8T5400	40 CONNECTOR	1
7K1181	41 STRAP-CABLE	1
3208448	42 CAP-NUT	2
1364192	43 BOLT (M6X1X35-MM)	1
