System And Components
8E-8862 ADAPTER GP-FAST FILL FUELS/N AAF1-UP
Group No: 8E-8862
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6G7803 | 1 VENT AS | 1 | |
| 6V9273 | 2 BALL | 1 | |
| 6Y0091 | 3 BLOCK AS | 1 | |
| 6Y0677 | 4 BRACKET AS | 1 | |
| 1F0748 | NUT-WELD (1/2-13-THD) | 2 | |
| 7T2413 | 5 SHAFT | 1 | |
| 8E3234 | 6 HOSE AS | 1 | |
| 9D0630 | 7 CAP-DUST | 1 | |
| 1018909 | 8 CAP AS-FILLER (LOCKING) | 1 | |
| 9X8600 | SEAL-O-RING | 1 | |
| 1833202 | 9 ADAPTER | 1 | |
| 2175703 | 10 RECEIVER (FAST FILL FUEL) | 1 | |
| 1B5170 | 11 PLUG-PIPE | 1 | |
| 1P4582 | 12 FLANGE-HALF | 4 | |
| 4J0527 | 13 SEAL-O-RING | 2 | |
| 4L6454 | 14 BOLT (3/8-16X1-IN) | 7 | |
| 5H6734 | 15 SEAL-O-RING | 1 | |
| 6V2686 | 16 CLIP | 1 | |
| 6V8801 | 17 NUT (3/8-16-THD) | 1 | |
| 7X0340 | 18 BOLT (1/2-13X6.5-IN) | 2 | |
| 7X0445 | 19 BOLT (1-1/4-7X5-IN) | 2 | |
| 7X0533 | 20 WASHER-HARD (34X55X6-MM THK) | 2 | |
| 8T4223 | 21 WASHER-HARD (13.5X25.5X3-MM THK) | 10 | |
| 8T4896 | 22 WASHER-HARD (10.2X18.5X2.5-MM THK) | 8 | |
| 8T8919 | 23 BOLT (1/2-13X1.75-IN) | 8 | |
| 5T8645 | KIT-VENT (FUEL TANK)(FAST FILL FUEL ADAPTER) | 1 |
