System And Components
180-7902 DRIVE GP-FINALS/N 4MN1-UP
Group No: 180-7902
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1807910 | 1 HUB AS | 1 | |
| 1374488 | GUARD | 1 | |
| 6V0329 | 2 CONE-BEARING (TAPERED ROLLER) | 1 | |
| 6V0330 | 3 CUP-BEARING (TAPERED ROLLER) | 1 | |
| 9G9181 | 4 RETAINER | 1 | |
| 8G8844 | 5 RING-LOCK | 1 | |
| 9G8639 | 6 GEAR-RING (94-TEETH) | 1 | |
| 8T9399 | 7 BOLT (3/4-10X2.25-IN) | 33 | |
| 8T4994 | 8 WASHER-HARD (20X36.5X3.5-MM THK) | 33 | |
| 9G8638 | 9 GEAR-PLANETARY (40-TEETH) | 3 | |
| 1B3978 | 10 CUP-BEARING (TAPERED ROLLER) | 6 | |
| 1564593 | 11 CONE-BEARING (TAPERED ROLLER) | 6 | |
| 9G9183 | 12 SHAFT | 3 | |
| 7X0346 | 13 BOLT (5/8-11X2-IN) | 3 | |
| 1807907 | 14 SPINDLE AS | 1 | |
| 1374489 | GUARD | 1 | |
| 2P3696 | 15 RETAINER | 3 | |
| 2B0947 | 16 BOLT (1/2-13X2.25-IN) | 10 | |
| 4L6454 | 17 BOLT (3/8-16X1-IN) | 3 | |
| 8T4896 | 18 WASHER-HARD (10.2X18.5X2.5-MM THK) | 3 | |
| 8G8845 | 19 COVER | 1 | |
| 2R0098 | 20 SEAL-O-RING | 1 | |
| 1880908 | 21 SEGMENT GP-SPROCKET | 1 | |
| 1P9005 | 22 SEAL-O-RING | 1 | |
| 2S4078 | 23 SEAL-O-RING | 1 | |
| 6V0439 | 24 PLUG-MAGNETIC (FINAL DRIVE, OIL FILL) | 1 | |
| 9G9175 | 25 CARRIER | 1 | |
| 9S4185 | 26 PLUG (3/4-16-THD)(FINAL DRIVE, OIL DRAIN) | 1 | |
| 3K0360 | 27 SEAL-O-RING | 1 | |
| 9H3360 | 28 SEAL-O-RING | 1 | |
| 8E2748 | 29 HUB-REACTION | 1 | |
| 9X7671 | 30 SEAL-LIP TYPE | 1 | |
| 6V0327 | 31 CUP-BEARING (TAPERED ROLLER) | 1 | |
| 6V0328 | 32 CONE-BEARING (TAPERED ROLLER) | 1 | |
| 6Y0859 | 33 SEAL GP-DUO-CONE | 1 | |
| 1D4628 | 34 BOLT (7/8-9X3.25-IN) | 26 | |
| 5P8249 | 35 WASHER-HARD (24X41.5X4-MM THK) | 26 | |
| 8T8919 | 36 BOLT (1/2-13X1.75-IN) | 2 | |
| 8T4223 | 37 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 1379810 | 38 SEAL-PACKING | 2 | |
| 1374490 | 39 RETAINER | 2 | |
| 8C6561 | 40 BOLT (5/16-18X1.375-IN) | 16 | |
| 8T4224 | 41 WASHER-HARD (8.8X16X2-MM THK) | 16 |
