System And Components
191-9530 LINES GP-POWER TRAIN OILS/N CCK1-366
Group No: 191-9530
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2W6225 | 1 CAP AS-OIL FILLER (POWER TRAIN) | 1 | |
| 5D1026 | 2 CLAMP-BAND | 4 | |
| 6B2882 | 3 SPACER (0.406X0.75X0.312-IN THK) | 3 | |
| 6V1230 | 4 ELBOW | 1 | |
| 6Y8473 | 5 VALVE GP-RELIEF (TORQUE CONVERTER OUTLET) | 1 | |
| 8C3447 | 6 CAP-DUST | 1 | |
| 8G5551 | 7 FLANGE | 1 | |
| 8G5654 | 8 GASKET | 1 | |
| 8G8589 | 9 HOUSING-SCREEN | 1 | |
| 8G9560 | 10 TUBE AS | 1 | |
| 8S9129 | 11 FILTER-MAGNETIC (POWER TRAIN OIL) | 1 | |
| 8S9130 | 12 SCREEN-SUCTION (POWER TRAIN OIL) | 1 | |
| 8T6703 | 13 CLAMP-HOSE | 2 | |
| 1142312 | 14 COVER AS | 1 | |
| 1391398 | 15 CLIP (LOOP) | 2 | |
| 1481928 | 16 VALVE-RELIEF (POWER TRAIN OIL) | 1 | |
| 1503026 | 17 ELBOW AS | 1 | |
| 6V4292 | ELBOW | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 1626966 | 18 TUBE AS | 1 | |
| 1731437 | 19 FLANGE-HALF | 2 | |
| 1734282 | 20 TUBE AS | 1 | |
| 1773382 | 21 MANIFOLD | 1 | |
| 1777185 | 22 HOSE AS | 1 | |
| 1777186 | 23 HOSE AS | 1 | |
| 1780568 | 24 FILTER GP-OIL (POWER TRAIN) | 1 | |
| 1789220 | 25 PLATE | 1 | |
| 1837264 | 26 VALVE AS-FLUID SAMPLING (POWER TRAIN OIL) | 1 | |
| 1856684 | 27 BREATHER AS (POWER TRAIN OIL FILLER) | 1 | |
| 1933849 | 28 VALVE GP-PRIORITY (POWER TRAIN OIL) | 1 | |
| 1946479 | 29 HOSE AS | 1 | |
| 1946480 | 30 HOSE AS | 1 | |
| 1946481 | 31 HOSE AS | 1 | |
| 1946482 | 32 HOSE AS | 1 | |
| 1946483 | 33 HOSE AS | 1 | |
| 1952037 | 34 FITTING AS | 2 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 0343679 | ADAPTER | 1 | |
| 1991222 | 35 GAUGE (OIL LEVEL)(POWER TRAIN OIL LEVEL) | 1 | |
| 2024365 | 36 PUMP GP-GEAR (POWER TRAIN OIL) | 1 | |
| 2034599 | 37 HOSE | 1 | |
| 2034600 | 38 HOSE | 1 | |
| 2143509 | 39 BRACKET AS | 1 | |
| 1707491 | STUD-WELD (M10X1.5X35-MM) | 1 | |
| 2143927 | 40 TUBE AS | 1 | |
| 2200907 | 41 HOSE | 1 | |
| 1488327 | 42 CONNECTOR AS | 1 | |
| 6V8637 | CONNECTOR | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488335 | 43 CONNECTOR AS | 2 | |
| 6V8635 | CONNECTOR | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1488360 | 44 ELBOW AS | 2 | |
| 6V9182 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1488408 | 45 PLUG AS | 1 | |
| 9S4183 | PLUG (1-1/16-12-THD) | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 1503065 | 46 ELBOW AS | 1 | |
| 6V0484 | ELBOW | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 1504047 | 47 ADAPTER AS | 1 | |
| 8T2353 | ADAPTER | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 1P3708 | 48 SEAL-RECTANGULAR | 1 | |
| 3J1907 | 49 SEAL-O-RING | 1 | |
| 3K0360 | 50 SEAL-O-RING | 1 | |
| 4D7388 | 51 CLIP | 2 | |
| 4J0520 | 52 SEAL-O-RING | 6 | |
| 4J0522 | 53 SEAL-O-RING | 3 | |
| 4L6454 | 54 BOLT (3/8-16X1-IN) | 3 | |
| 4P8134 | 55 CLIP (LADDER) | 1 | |
| 5D0718 | 56 CLIP (LOOP) | 4 | |
| 5K1770 | 57 SEAL-O-RING | 1 | |
| 5P8066 | 58 SEAL-O-RING | 1 | |
| 6H3977 | 59 SEAL-O-RING | 1 | |
| 6L1651 | 60 SEAL-O-RING | 1 | |
| 6L5359 | 61 SEAL-O-RING | 1 | |
| 6V1889 | 62 CLIP (LOOP) | 3 | |
| 7X7729 | 63 WASHER (11X25X3-MM THK) | 6 | |
| 8C3205 | 64 FLANGE-HALF | 2 | |
| 8C3206 | 65 FLANGE-HALF | 4 | |
| 8M4988 | 66 SEAL-O-RING | 1 | |
| 8M5254 | 67 SEAL-O-RING | 5 | |
| 8T4121 | 68 WASHER-HARD (11X21X2.5-MM THK) | 36 | |
| 8T4133 | 69 NUT (M10X1.5-THD) | 4 | |
| 8T4136 | 70 BOLT (M10X1.5X25-MM) | 6 | |
| 8T4137 | 71 BOLT (M10X1.5X20-MM) | 4 | |
| 8T4172 | 72 BOLT (M10X1.5X80-MM) | 3 | |
| 8T4183 | 73 BOLT (M12X1.75X40-MM) | 4 | |
| 8T4184 | 74 BOLT (M12X1.75X45-MM) | 8 | |
| 8T4195 | 75 BOLT (M10X1.5X30-MM) | 2 | |
| 8T4196 | 76 BOLT (M10X1.5X35-MM) | 20 | |
| 8T4223 | 77 WASHER-HARD (13.5X25.5X3-MM THK) | 16 | |
| 8T4896 | 78 WASHER-HARD (10.2X18.5X2.5-MM THK) | 3 | |
| 8T4956 | 79 BOLT (M12X1.75X35-MM) | 4 | |
| 8T6466 | 80 BOLT (M10X1.5X60-MM) | 6 | |
| 9M4218 | 81 SEAL-O-RING | 1 | |
| 9X4609 | 82 SEAL-O-RING | 1 |
