Assembly
100%

128-8102 INSTRUMENT GPS/N 6JN1-418

Group No: 128-8102
Part NumberPart NameQty
3S20931 STRAP-CABLE4
7N58762 LAMP (24-VOLT, 0.2-AMPERE)2
9G76413 SWITCH GP-START (ENGINE, KEY)1
9X67724 STRAP-CABLE4
13394055 SWITCH AS-PUSH BUTTON (AUTO SHIFT)1
3E3371WEDGE-RECEPTACLE LOCK (3-PIN)1
3K0835NUT (5/8-24-THD)1
6F0253LOCKWASHER1
8T8729PIN-CONNECTOR (16-GA TO 20-GA)3
1028803KIT-RECEPTACLE (3-PIN)1
10055676 BEZEL1
10058957 MODULE GP-QUAD GAUGE1
10687018 PLATE1
10719649 SCREW-PAN HEAD (6-19X0.5-IN)4
109718910 SWITCH AS-ROTARY (LIGHTS)1
6V8376SCREW-MACHINE (8-32X0.25-IN)7
9B7233LOCKWASHER7
110610911 KNOB-CONTROL1
136208712 HARNESS AS-DASH1
112078813 FILM-PANEL1
116145614 PLATE AS1
1F0750NUT-WELD (3/8-16-THD)3
4P8134CLIP (LADDER)(FLAT)1
7T1099LINK2
6V963215 NUT-WELD (M6X1-THD)7
116620316 RESISTOR AS1
1028802KIT-RECEPTACLE (2-PIN)1
3E3365WEDGE-RECEPTACLE LOCK (2-PIN)1
8T8729PIN-CONNECTOR (16-GA TO 20-GA)2
116796417 MOUNT2
117992018 PANEL-DASH (LIGHT)1
122712719 NUT-SPECIAL (NYLON)10
123030420 INDICATOR AS (ACTION)1
1151748LAMP (24-VOLT, 3-WATT)1
1230306SOCKET AS1
123929421 LAMP (24-VOLT)(0.08 AMP)3
125046922 FILM-IDENTIFICATION (AUTOSHIFT SWITCH)1
125047023 FILM-IDENTIFICATION (DISPLAY MODE SWITCH)1
125074824 PANEL-DASH1
125340125 CONTROL GP-DISPLAY ELECTRONIC (LED DISPLAY)1
126940126 CONTROL GP-ELECTRONIC (OPERATOR MONITOR)1
4P813427 CLIP (LADDER)(FLAT)1
5M306228 BOLT (3/8-16X0.75-IN)2
5P107529 WASHER-HARD (10.2X22.5X3-MM THK)2
7Y725630 SCREW-TRUSS HEAD (M4X0.7X35-MM)4
8T417131 BOLT (M6X1X12-MM)3
9X204532 SCREW-TRUSS HEAD (M6X1X20-MM)7
8T420533 WASHER-HARD (7.2X14.5X2-MM THK)1
133940534 SWITCH AS-PUSH BUTTON (OPERATOR MONITOR)1
3E3371WEDGE-RECEPTACLE LOCK (3-PIN)1
3K0835NUT (5/8-24-THD)1
6F0253LOCKWASHER1
8T8729PIN-CONNECTOR (16-GA TO 20-GA)3
1028803KIT-RECEPTACLE (3-PIN)1
133940535 SWITCH AS-PUSH BUTTON (START AID)1
3E3371WEDGE-RECEPTACLE LOCK (3-PIN)1
3K0835NUT (5/8-24-THD)1
6F0253LOCKWASHER1
8T8729PIN-CONNECTOR (16-GA TO 20-GA)3
1028803KIT-RECEPTACLE (3-PIN)1
133940536 SWITCH AS-PUSH BUTTON (AUTO KICKDOWN)1
3E3371WEDGE-RECEPTACLE LOCK (3-PIN)1
3K0835NUT (5/8-24-THD)1
6F0253LOCKWASHER1
8T8729PIN-CONNECTOR (16-GA TO 20-GA)3
1028803KIT-RECEPTACLE (3-PIN)1
134725537 FILM-IDENTIFICATION (AUTOMATIC KICKDOWN)1
141497638 SCREW-WASHER HEAD (4-40X0.5-IN)6
8C635439 CAP-RECEPTACLE (ET CONNECTOR)1
8E784040 CLIP1
8T033741 SCREW-MACHINE (M4X0.7X12-MM)3
122055942 GUARD-VANDALISM1
8T289543 LOCK GP-CYLINDER1
128615744 PLATE1
133897945 CONTROL GP-DISPLAY ELECTRONIC (LED DISPLAY)1
135217246 PLATE1
136911947 BRACKET1
8T265948 LOCKNUT (M4X0.7-THD)3
