System And Components
105-9666 PLATFORM GP-CABS/N 2YN1-UP; 3ZN1-UP; 4MN1-UP; 5LN1-UP; 6JN1-UP; 7KN1-UP; 8LN1-UP; 9PN1-UP; DMP1-UP
Group No: 105-9666
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1712133 | 1 SLEEVE | 4 | |
| 3T3462 | 2 PLATE | 4 | |
| 6J0488 | 3 SCREW-BUTTON HEAD (3/8-16X0.875-IN) | 21 | |
| 8E9299 | 4 PLATE | 1 | |
| 8T4943 | 5 PLUG | 1 | |
| 1351609 | 6 SUPPORT AS-FOOT | 2 | |
| 1078772 | 7 PLATFORM AS | 1 | |
| 7T1099 | LINK | 9 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 14 | |
| 4P8134 | CLIP | 2 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 1 | |
| 1089638 | 8 PLATE AS | 1 | |
| 1F0750 | 9 NUT-WELD (3/8-16-THD) | 1 | |
| 1409829 | 10 FLOORPLATE AS | 1 | |
| 1412406 | PANEL | 1 | |
| 1178131 | 11 MOUNT AS | 8 | |
| 1408618 | 12 PLATE | 1 | |
| 5P1075 | 13 WASHER-HARD (10.2X22.5X3-MM THK) | 38 | |
| 5P1076 | 14 WASHER-HARD (13.5X30X4-MM THK) | 4 | |
| 7X0582 | 15 WASHER-HARD (20X44.5X6-MM THK) | 4 | |
| 5M3062 | 16 BOLT (3/8-16X0.75-IN) | 19 | |
| 5C6565 | 17 BOLT (1/2-13X1.125-IN) | 4 | |
| 7X0373 | 18 BOLT (3/4-10X5.5-IN) | 4 | |
| 1356269 | 19 COVER | 1 | |
| 1412408 | 20 FLOORPLATE AS | 1 | |
| 1412407 | PANEL | 1 | |
| 1179966 | 21 PLUG | 2 | |
| 8T4896 | 22 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 1090532 | 23 COVER AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 8 | |
| 5D0353 | 24 BOLT-LOCKING (3/8-16X1-IN) | 2 | |
| 4H0408 | 25 PLUG-PROTECTION | 11 | |
| 1J0245 | 26 PLUG-PROTECTION | 2 |
