System And Components
137-0219 FRAME GP-TELESCOPING RECOIL -LHS/N AAX1-UP
Group No: 137-0219
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3T2077 | 1 BEARING | 1 | |
| 3W1852 | 2 RING-RETAINING | 1 | |
| 9X4582 | 3 SEAL AS | 1 | |
| 8T5071 | GUARD-SEAL | 1 | |
| 8T4139 | 4 BOLT (M12X1.75X30-MM) | 14 | |
| 8T4223 | 5 WASHER-HARD (13.5X25.5X3-MM THK) | 26 | |
| 8T4136 | 6 BOLT (M10X1.5X25-MM) | 4 | |
| 1080156 | 7 FRAME AS | 1 | |
| 4B4158 | SCREW-DRIVE (NO 4X0.25-IN) | 4 | |
| 6V2226 | PLATE-WARNING (RECOIL SPRING) | 1 | |
| 3T1162 | 8 BUSHING | 1 | |
| 7T5886 | 9 DOWEL | 2 | |
| 8E1212 | 10 COVER AS | 1 | |
| 5P9891 | PLATE-WARNING (HIGH PRESSURE CYLINDER) | 1 | |
| 7B3028 | SCREW-DRIVE (NO 4X 3/16-IN) | 4 | |
| 8T4184 | 11 BOLT (M12X1.75X45-MM) | 12 | |
| 1445574 | 12 GUIDE AS | 2 | |
| 8T7532 | FILM-WARNING (RECOIL SPRING) | 1 | |
| 1B5174 | 13 PLUG-PIPE | 2 | |
| 8T4121 | 14 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 9U8492 | 15 TRACK ADJUSTER & RECOIL GP | 1 | |
| 5H6734 | 16 SEAL-O-RING | 1 | |
| 1604104 | 17 STRIP | 2 | |
| 1893032 | 18 STRIP | 2 | |
| 1370220 | 19 FRAME AS (LH) | 1 | |
| 7P8370 | 20 BEARING | 1 | |
| 7T5886 | 21 DOWEL | 2 | |
| 7J1333 | 22 BEARING | 1 | |
| 1632171 | 23 GUARD AS (LH) | 1 | |
| 1632172 | 24 GUARD AS (RH) | 1 | |
| 1632178 | 25 GUARD AS (LH) | 1 | |
| 1632177 | 26 GUARD AS (RH) | 1 | |
| 9G1962 | 27 HOOK | 2 | |
| 9U8482 | 28 BUSHING | 2 | |
| 8G9530 | 29 SHIM (8-MM THK) | 4 |
