System And Components
283-8673 FRAME GP-TELESCOPING RECOIL -HEAVY-DUTY, RHS/N JWD1-UP
Group No: 283-8673
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9X4582 | 1 SEAL AS | 1 | |
| 1604103 | 2 STRIP | 2 | |
| 1893032 | 3 STRIP | 2 | |
| 2230659 | 4 TRACK ADJUSTER & RECOIL GP | 1 | |
| 2244122 | 5 FRAME AS (FRONT) | 1 | |
| 3T1162 | 5A BUSHING | 1 | |
| 4B4158 | 5B SCREW-DRIVE (NO 4X0.25-IN) | 4 | |
| 2541686 | 5C PLATE-WARNING (RECOIL SPRING) | 1 | |
| 7T5886 | 5D DOWEL | 2 | |
| 1632175 | 5E GUARD AS (LH) | 1 | |
| 1632176 | 5F GUARD AS (RH) | 1 | |
| 2358497 | 6 FRAME AS (RH) | 1 | |
| 2213197 | 6A BUSHING | 1 | |
| 2213200 | 6B BUSHING | 1 | |
| 7T5886 | 6C DOWEL | 2 | |
| 1632173 | 6D GUARD AS | 1 | |
| 1632174 | 6E GUARD AS | 1 | |
| 2689709 | 7 GUIDE AS | 2 | |
| 2413720 | 7A FILM-WARNING (RECOIL SPRING) | 1 | |
| 2689710 | 8 COVER AS | 1 | |
| 7B3028 | 8A SCREW-DRIVE (NO 4X 3/16-IN) | 4 | |
| 8E1211 | 8B COVER | 1 | |
| 2531346 | 8C PLATE-WARNING (HIGH PRESSURE CYLINDER) | 1 | |
| 1B5174 | 9 PLUG-PIPE | 2 | |
| 3T2077 | 10 BEARING | 1 | |
| 3W1852 | 11 RING-RETAINING | 1 | |
| 5H6734 | 12 SEAL-O-RING | 1 | |
| 8T4121 | 13 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4136 | 14 BOLT (M10X1.5X25-MM) | 4 | |
| 8T4139 | 15 BOLT (M12X1.75X30-MM) | 16 | |
| 8T4184 | 16 BOLT (M12X1.75X45-MM) | 12 | |
| 8T4223 | 17 WASHER-HARD (13.5X25.5X3-MM THK) | 28 |
