220-2800 PLATFORM GP-OPERATORS/N SMC1-UP; GCT1-UP

Group No: 220-2800
Part NumberPart NameQty
4H04071 PLUG-PROTECTION6
5P75092 PLUG-BUTTON2
6T45563 COVER1
6T45574 GASKET1
6V85476 PLUG-BUTTON1
6Y02067 RETAINER2
7G48248 STRAP1
8E779110 STRAP1
8T494311 PLUG1
117813112 MOUNT AS8
117996613 PLUG1
161395814 GASKET1
164075815 BOLT (9/16-18X2-IN)1
165685716 PAD AS-RUBBER1
170025117 STRIP2
184098218 SCREW-PAN HEAD (M6X1X16-MM)12
185207619 SUPPORT AS (FOOT)2
185366620 SLEEVE4
205220321 PLATE1
198970722 SCREW-TRUSS HEAD (M6X1X35-MM)2
225948023 PLATFORM GP1
418552024 PLATE AS1
237426825 COVER AS-PLATFORM1
237426926 PLATE AS1
237427027 PLATE AS1
239511328 COVER AS1
2G0391SCREW2
1315492RETAINER-CAPTIVE2
241434329 FLOORPLATE AS1
2370205FLOORPLATE AS1
1843289PANEL1
2414342GASKET1
241434530 FLOORPLATE AS1
2370204FLOORPLATE AS1
1843285PANEL1
2414344GASKET1
241434631 PLATE AS1
241434832 GASKET1
241434933 GASKET1
242840534 BRACKET AS1
242840735 GASKET1
243516836 GASKET1
243517037 COVER AS1
248886638 CAP4
5C289039 NUT (M6X1-THD)4
5P107640 WASHER-HARD (13.5X30X4-MM THK)4
6T871441 WASHER-HARD (28X125X12-MM THK)4
6V735742 BOLT (M6X1X25-MM)4
7X772943 WASHER (11X25X3-MM THK)58
8T413645 BOLT (M10X1.5X25-MM)38
8T413746 BOLT (M10X1.5X20-MM)3
8T413947 BOLT (M12X1.75X30-MM)4
8T416748 WASHER-HARD (26X44X4-MM THK)4
8T419549 BOLT (M10X1.5X30-MM)11
8T419650 BOLT (M10X1.5X35-MM)6
8T464951 BOLT (M24X3X140-MM)4
9D376952 GROMMET1
9X825653 WASHER (6.6X12X2-MM THK)10
5P990954 SEAL (0.03-M)
3E389255 SEAL (31-CM)
9P657157 PLUG1
