System And Components
338-8585 TRACK ADJUSTER & RECOIL GPS/N MDB1-UP
Group No: 338-8585
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7J1336 | 1 BEARING | 1 | |
| 8T2185 | 2 SEAL-U-CUP | 1 | |
| 9W6074 | 3 RETAINER | 1 | |
| 1908609 | 4 VALVE-FILL (GREASE) | 1 | |
| 2994198 | 5 WASHER-THRUST (75.25X101.2X5-MM THK) | 1 | |
| 3044272 | 6 YOKE | 1 | |
| 3083053 | 7 SEAL-WIPER | 3 | |
| 3461107 | 8 CABLE AS | 1 | |
| 3585198 | 9 PISTON | 1 | |
| 3589064 | 10 BLOCK | 1 | |
| 3620152 | 11 CYLINDER AS | 1 | |
| 3630712 | 12 BULKHEAD AS | 1 | |
| 3660376 | 13 CYLINDER AS | 1 | |
| 3278525 | 14 PLUG AS-RELIEF | 1 | |
| 1J9671 | SEAL-O-RING | 1 | |
| 1984778 | 15 WASHER-HARD (13.5X30X12-MM THK) | 8 | |
| 1M8649 | 16 RING-RETAINING | 2 | |
| 2721777 | 17 WASHER-HARD (11X18.5X15-MM THK) | 1 | |
| 5B0651 | 18 FITTING-STRAIGHT | 1 | |
| 6J1038 | 19 SEAL-O-RING | 2 | |
| 6J2797 | 20 RING-WEAR | 2 | |
| 7X0632 | 21 WASHER-HARD (11X36X6-MM THK) | 2 | |
| 7X2552 | 22 BOLT (M16X2X30-MM) | 1 | |
| 8H8830 | 23 RING-RETAINING | 1 | |
| 8T0363 | 24 BOLT (M24X3X120-MM) | 4 | |
| 8T4122 | 25 WASHER-HARD (17X32X3.5-MM THK) | 1 | |
| 8T4167 | 26 WASHER-HARD (26X44X4-MM THK) | 4 | |
| 8T4183 | 27 BOLT (M12X1.75X40-MM) | 8 | |
| 8T4194 | 28 BOLT (M12X1.75X50-MM) | 2 | |
| 8T4196 | 29 BOLT (M10X1.5X35-MM) | 2 | |
| 8T4223 | 30 WASHER-HARD (13.5X25.5X3-MM THK) | 6 | |
| 8T4910 | 31 BOLT (M12X1.75X60-MM) | 4 | |
| 4405170 | 32 FILM-WARNING (HIGH PRESSURE, READ OMM) | 1 |
