System And Components
162-9581 CASE & FRAME GPS/N ACL1-1125
Group No: 162-9581
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1068186 | 1 VALVE AS-DRAIN (ECOLOGY)(CASE) | 1 | |
| 6Y2446 | 2 TUBE AS | 2 | |
| 3G6402 | 3 BUSHING | 2 | |
| 8T2502 | 4 BOLT (3/8-16X1.125-IN) | 4 | |
| 3P8845 | 5 BUSHING | 2 | |
| 8T4896 | 6 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 6F0711 | 7 SEAL-O-RING | 1 | |
| 1068187 | 8 PLUG-DRAIN | 1 | |
| 8P0420 | 9 BEARING | 2 | |
| 9W0330 | 10 BEARING | 4 | |
| 7M8480 | 11 DOWEL | 1 | |
| 1629580 | 12 CASE & FRAME AS | 1 | |
| 7T1099 | 13 LINK | 15 | |
| 3Y7829 | 14 BOSS (3/8-16-THD) | 3 | |
| 9K3050 | 15 STUD-WELD | 4 | |
| 1F0750 | 16 NUT-WELD (3/8-16-THD) | 4 | |
| 5P1075 | 17 WASHER-HARD (10.2X22.5X3-MM THK) | 1 | |
| 2K4973 | 18 LOCKNUT (3/8-16-THD) | 1 | |
| 1885141 | 19 PLATE | 1 | |
| 2R1694 | 20 SPACER | 1 | |
| 7S3916 | 21 CLIP (TAB) | 1 | |
| 7S3919 | 22 CLIP (SLOT) | 1 | |
| 7G8947 | 23 PLATE | 1 | |
| 3H4776 | 24 BOSS (3/8-16X1.25-IN) | 2 | |
| 8P6334 | 25 LUG | 16 | |
| 9W0329 | 26 PLATE | 2 | |
| 9W0332 | 27 SUPPORT | 1 | |
| 9W0333 | 28 SUPPORT | 1 | |
| 9P6544 | 29 SUPPORT | 1 | |
| 9W2345 | 30 PLATE | 2 | |
| 1F0748 | 31 NUT-WELD (1/2-13-THD) | 6 | |
| 1102966 | 32 TRUNNION | 1 | |
| 7J5225 | 33 FITTING (1-1/16-12-THD) | 1 |
