System And Components
337-7605 BAR AS-STRIKER -REARS/N REX1-UP
Group No: 337-7605
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1L4418 | 1 SPRING-SHUTOFF | 2 | |
| 1P2841 | 2 SPACER (0.531X1X0.69-IN THK) | 2 | |
| 1Q3162 | 3 BRACKET AS | 1 | |
| 8T5911 | NUT-WELD (1/2-13-THD) | 2 | |
| 1Z9932 | 4 HINGE AS | 2 | |
| 1Z9933 | 5 HINGE AS | 2 | |
| 8T4896 | 6 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 3B4617 | 7 PIN-COTTER | 4 | |
| 8F3556 | 8 SPACER (0.75X1.25X1-IN THK) | 4 | |
| 8T1579 | 9 PLATE | 1 | |
| 8T9496 | 10 LOCKNUT (9/16-18-THD) | 2 | |
| 8Y6400 | 11 LATCH GP (T-BAR, COMPARTMENT) | 1 | |
| 8T4223 | 12 WASHER-HARD (13.5X25.5X3-MM THK) | 10 | |
| 9Z9211 | 13 PLATE | 2 | |
| 9Z9214 | 14 ROD AS | 2 | |
| 1Z9787 | BOSS | 1 | |
| 2569990 | 15 COVER AS-ACCESS | 1 | |
| 3377612 | 16 DOOR AS (LH) | 1 | |
| 3377613 | 17 DOOR AS (RH) | 1 | |
| 8T4222 | 18 WASHER-PLATED (11X32X2.5-MM THK) | 1 | |
| 2K4973 | 19 LOCKNUT (3/8-16-THD) | 2 | |
| 5P1076 | 20 WASHER-HARD (13.5X30X4-MM THK) | 4 | |
| 5S7382 | 21 BOLT (3/8-16X1.375-IN) | 2 | |
| 6V7687 | 22 LOCKNUT (M12X1.75-THD) | 2 | |
| 7B9665 | 23 PLUG | 1 | |
| 8T4136 | 24 BOLT (M10X1.5X25-MM) | 1 | |
| 8T4176 | 25 BOLT (M12X1.75X90-MM) | 2 | |
| 8T4183 | 26 BOLT (M12X1.75X40-MM) | 8 |
