454-2958 BODY AS-CATALYTIC CONVERTER4X4X3

Group No: 454-2958
Part NumberPart NameQty
38810091 HATCH AS1
6C3677RIVET-POP4
4305967PLATE-WARNING (HOT SURFACE, HANDS CLEAR)1
38810132 GASKET AS1
45429693 HATCH AS1
8K7186NUT-WELD (7/16-14-THD)2
8T5360WASHER (12X22.5X2.5-MM THK)2
8T8916BOLT (7/16-14X1.5-IN)2
4393938BRACKET-LINK2
6C3677RIVET-POP4
4305967PLATE-WARNING (HOT SURFACE, HANDS CLEAR)1
45429714 PLATE AS2
8T3490NUT-WELD (M10X1.5-THD)14
45429725 PLATE AS2
8T3490NUT-WELD (M10X1.5-THD)13
45429746 CHANNEL6
45429757 CHANNEL2
45429788 PLATE AS2
8T3490NUT-WELD (M10X1.5-THD)11
45429799 PLATE AS2
8T3490NUT-WELD (M10X1.5-THD)11
454298210 GASKET AS1
454298311 PLATE2
454298412 PLATE2
454298513 CHANNEL1
454444114 FRAME AS1
3662394BOSS22
4544440BRACKET AS2
6C3210BOLT (7/8-9X3-IN)1
7X0449NUT-FULL (7/8-9-THD)1
8C6913WASHER-HARD (24X41.5X4-MM THK)1
4393939BRACKET AS-LINK1
4575684BRACKET AS2
6C3210BOLT (7/8-9X3-IN)1
7X0449NUT-FULL (7/8-9-THD)1
8C6913WASHER-HARD (24X41.5X4-MM THK)1
4393939BRACKET AS-LINK1
455120015 PLATE2
455120116 PLATE2
7X058417 WASHER-HARD (13.5X20.5X2-MM THK)8
151913018 BOLT-SPECIAL2
2Y582919 NUT (M10X1.5-THD)18
6V182020 BOLT (M10X1.5X30-MM)21
6V583921 WASHER (11X21X2.5-MM THK)39
6V880122 NUT (3/8-16-THD)2
8T412123 WASHER-HARD (11X21X2.5-MM THK)98
8T413824 BOLT (M6X1X20-MM)26
8T418525 BOLT (M10X1.5X50-MM)98
454348027 WASHER (7.1X38.1X1.3-MM THK)26
473384128 PLATE8
439290029 SPACER (17X30X5-MM THK)8
