System And Components
457-8417 BODY AS-CATALYTIC CONVERTER4X3X3
Group No: 457-8417
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3881009 | 1 HATCH AS | 1 | |
| 6C3677 | RIVET-POP | 4 | |
| 4305967 | PLATE-WARNING (HOT SURFACE, HANDS CLEAR) | 1 | |
| 3881013 | 2 GASKET AS | 1 | |
| 4542969 | 3 HATCH AS | 1 | |
| 8K7186 | NUT-WELD (7/16-14-THD) | 2 | |
| 8T5360 | WASHER (12X22.5X2.5-MM THK) | 2 | |
| 8T8916 | BOLT (7/16-14X1.5-IN) | 2 | |
| 4393938 | BRACKET-LINK | 2 | |
| 6C3677 | RIVET-POP | 4 | |
| 4305967 | PLATE-WARNING (HOT SURFACE, HANDS CLEAR) | 1 | |
| 4542971 | 4 PLATE AS | 2 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 14 | |
| 4542972 | 5 PLATE AS | 2 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 13 | |
| 5130823 | 6 SEAL GP-EXHAUST | 1 | |
| 4542978 | 7 PLATE AS | 2 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 11 | |
| 4542979 | 8 PLATE AS | 2 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 11 | |
| 4542982 | 9 GASKET AS | 1 | |
| 4542983 | 10 PLATE | 2 | |
| 4542984 | 11 PLATE | 2 | |
| 4389588 | 12 SENSOR GP-CATALYTIC CONVERTER (INLET) | 1 | |
| 4543480 | 13 WASHER (7.1X38.1X1.3-MM THK) | 26 | |
| 4551200 | 14 PLATE | 2 | |
| 4551201 | 15 PLATE | 2 | |
| 4578422 | 16 FRAME AS | 1 | |
| 3662392 | BOSS (M6X1X49.4-MM) | 4 | |
| 4575684 | BRACKET AS | 2 | |
| 6C3210 | BOLT (7/8-9X3-IN) | 1 | |
| 7X0449 | NUT-FULL (7/8-9-THD) | 1 | |
| 8C6913 | WASHER-HARD (24X41.5X4-MM THK) | 1 | |
| 4393939 | BRACKET AS-LINK | 1 | |
| 4544440 | BRACKET AS | 2 | |
| 6C3210 | BOLT (7/8-9X3-IN) | 1 | |
| 7X0449 | NUT-FULL (7/8-9-THD) | 1 | |
| 8C6913 | WASHER-HARD (24X41.5X4-MM THK) | 1 | |
| 4393939 | BRACKET AS-LINK | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 3 | |
| 4385325 | 17 SENSOR GP-CATALYTIC CONVERTER (OUTLET) | 1 | |
| 4733841 | 18 PLATE | 8 | |
| 1519130 | 19 BOLT-SPECIAL | 2 | |
| 5130840 | 20 BRACKET AS | 2 | |
| 4392900 | 21 SPACER (17X30X5-MM THK) | 8 | |
| 5132909 | 22 LINES GP-EXHAUST | 1 | |
| 6V8837 | 23 BOLT (M6X1X16-MM) | 8 | |
| 6V8801 | 24 NUT (3/8-16-THD) | 2 | |
| 7X0584 | 25 WASHER-HARD (13.5X20.5X2-MM THK) | 8 | |
| 8T4121 | 26 WASHER-HARD (11X21X2.5-MM THK) | 98 | |
| 8T4138 | 27 BOLT (M6X1X20-MM) | 26 | |
| 8T4185 | 28 BOLT (M10X1.5X50-MM) | 98 | |
| 9X8256 | 29 WASHER (6.6X12X2-MM THK) | 8 | |
| 2901993 | 30 STRAP-CABLE | 1 | |
| 4189798 | 31 BRACKET | 1 | |
| 3768476 | 33 INJECTOR AS-DEF | 1 | |
| 1094441 | 34 PLUG | 1 | |
| 6V8182 | 35 NUT (3/4-10-THD) | 8 | |
| 7H3171 | 36 PLUG-PIPE | 3 | |
| 8T4994 | 37 WASHER-HARD (20X36.5X3.5-MM THK) | 16 | |
| 3368237 | 38 BOLT (3/4-10X76.2-IN) | 8 | |
| 3332400 | 39 GASKET-DEF INJECTOR | 1 |
