System And Components
251-2175 PANEL GP-POWER SUPPLYS/N CSY245-252
Group No: 251-2175
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1069586 | 1 SEAL-O-RING | 1 | |
| 2006266 | 2 FUSE (7-AMPERE) | 2 | |
| 2006265 | 3 FUSE (4-AMPERE) | 2 | |
| 2008452 | 4 SENSOR-VACUUM (FLYWHEEL BEARING) | 1 | |
| 2012604 | 5 BOARD AS-CIRCUIT (AC INTERFACE) | 1 | |
| 2012631 | 6 SWITCH-PUSH BUTTON (EMERGENCY MODULE OFF) | 1 | |
| 2012633 | 7 SWITCH-KEY (CONTROL) | 1 | |
| 2364885 | KEY (CONTROL) | 1 | |
| 2012706 | 8 BOARD AS-CIRCUIT (POWER DISTRIBUTION) | 1 | |
| 2014708 | 9 CONNECTOR | 2 | |
| 2014775 | 10 FUSE (500-AMPERE) | 3 | |
| 2015230 | 11 FUSE (500-AMPERE) | 3 | |
| 2028901 | 12 TRANSFORMER (230-VOLT) | 1 | |
| 2432251 | 13 BOARD AS-CIRCUIT (APC1+ (MMS)) | 1 | |
| 2031007 | 14 FAN GP-CIRCULATING | 6 | |
| 2270942 | 15 SEAL-O-RING | 2 | |
| 2274833 | 16 PANEL GP-ELECTRICAL (DC BUS) | 1 | |
| 2274836 | 17 BOARD AS-CIRCUIT (DC INTERFACE) | 1 | |
| 2274842 | 18 COVER | 1 | |
| 2305687 | 19 PLUG AS | 4 | |
| 2310489 | SEAL-O-RING | 1 | |
| 2307235 | 20 SEAL-O-RING | 2 | |
| 2310489 | 21 SEAL-O-RING | 4 | |
| 2313504 | 22 PUMP & MOTOR GP-VACUUM | 1 | |
| 2400820 | 23 BLOCK-FUSE (2-POLE) | 2 | |
| 2402261 | 24 PIN AS | 2 | |
| 2402513 | 25 RETAINER | 1 | |
| 2402516 | 26 SCREEN | 2 | |
| 2402526 | 27 FILTER ELEMENT-ENCLOSURE AIR | 2 | |
| 2402531 | 28 LATCH-DOOR | 2 | |
| 2402661 | 29 CLAMP | 4 | |
| 2402670 | 30 SEAL | 1 | |
| 2402683 | 31 GUARD | 1 | |
| 2423317 | 32 PLATE | 2 | |
| 2423318 | 33 PLATE (REAR) | 1 | |
| 2435347 | 34 TUBING | 1 | |
| 2441409 | 35 FLYWHEEL GP-POWER SUPPLY | 1 | |
| 2505511 | 36 FILTER AS-ELECTRICAL (AC) | 1 | |
| 2505512 | 37 BOARD AS-CIRCUIT (EMI FILTER) | 1 | |
| 2505513 | 38 CONTACTOR | 2 | |
| 2505523 | 39 SWITCH AS (STATIC BYPASS) | 1 | |
| 2593199 | 40 BOARD AS-CIRCUIT (EMI FILTER) | 1 | |
| 2947319 | 41 SWITCH AS-PUSH BUTTON (EMERGENCY POWER OFF) | 1 | |
| 2P2975 | 42 SEAL-O-RING | 1 | |
| 3635174 | 43 SEAL-O-RING | 2 | |
| 3731693 | 44 BOARD AS-CIRCUIT (APC1+ (MMS)) | 1 | |
| 3731694 | 45 MODULE GP-CONVERTER (RH) | 1 | |
| 3731700 | 46 BOARD AS-CIRCUIT (UNIVERSAL NETWORK INTERFACE) | 1 | |
| 3783426 | 47 MODULE GP-CONVERTER (LH) | 3 | |
| 3783428 | 48 BOARD AS-CIRCUIT (OPTICAL, ROTARY POSITION)(FLYWHEEL) | 2 | |
| 2307235 | SEAL-O-RING | 1 | |
| 3783429 | 49 BOARD AS-CIRCUIT (FLYWHEEL INTERFACE) | 1 | |
| 3788319 | 50 BOARD AS-CIRCUIT (FIELD COIL DRIVER) | 1 | |
| 2795201 | FUSE (3-AMPERE) | 1 | |
| 3927015 | 51 BOARD AS-CIRCUIT (FAN MONITOR) | 1 | |
| 4157134 | 52 DOOR (RIGHT) | 1 | |
| 2402516 | SCREEN | 1 | |
| 4260414 | 53 POWER SUPPLY GP | 2 | |
| 4260433 | 54 DOOR (LEFT) | 1 | |
| 2402516 | SCREEN | 1 |
