System And Components
521-9397 FORK GP-LOGS/N RXT50001-UP
Group No: 521-9397
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2V1195 | 1 SPACER-SPECIAL | 4 | |
| 1598035 | 3 FILM-WARNING (CRUSH HAZARD, STAY BACK) | 2 | |
| 1598036 | 4 FILM-WARNING (READ OMM) | 1 | |
| 2533431 | 5 FILM-WARNING (CRUSH HAZARD, FORKS, READ OMM) | 2 | |
| 3538637 | 6 HOSE AS | 1 | |
| 3736439 | 7 HOSE AS | 2 | |
| 3854590 | 8 HOSE AS | 1 | |
| 3953098 | 9 CYLINDER GP-FORK | 2 | |
| 4202546 | 13 HOSE AS | 1 | |
| 4217241 | 14 HOSE AS | 1 | |
| 4391588 | 15 COUPLING (QUICK DISCONNECT, FEMALE) | 1 | |
| 4391589 | 16 COUPLING AS (QUICK DISCONNECT, MALE) | 1 | |
| 4711015 | 18 CAP AS | 1 | |
| 4F7952 | SEAL-O-RING | 1 | |
| 4711016 | 19 CAP AS | 1 | |
| 1416263 | 20 PLATE | 8 | |
| 1416264 | 21 PLATE | 4 | |
| 2765472 | 22 TUBE | 1 | |
| 2P1293 | 23 LOCKNUT (1-3/16-12-THD) | 2 | |
| 3125694 | 24 SETSCREW (1/4-20X0.25-IN) | 1 | |
| 3853395 | 25 PIN AS | 2 | |
| 3855357 | 26 PIN AS | 2 | |
| 3D2824 | 27 SEAL-O-RING | 2 | |
| 4157387 | 28 CLAMP AS | 1 | |
| 7K9528 | 28A BUSHING | 4 | |
| 3B8489 | 28B FITTING-GREASE | 2 | |
| 7K9205 | 28C SEAL-LIP TYPE | 4 | |
| 5406595 | 29 CARRIAGE AS-FORK | 1 | |
| 2C9259 | 29A PLATE-IDENTIFICATION (CAT) | 2 | |
| 2853254 | 29B PLATE (PROTECTOR) | 1 | |
| 3284365 | 29C PLATE | 2 | |
| 5639799 | 30 TINE AS | 2 | |
| 5652810 | 31 PIN AS | 2 | |
| 5654143 | 32 COLLAR | 2 | |
| 6S7133 | 34 PIN | 2 | |
| 6V7742 | 35 NUT-FULL (M20X2.5-THD) | 4 | |
| 6V8149 | 36 NUT (M12X1.75-THD) | 4 | |
| 6V8637 | 37 CONNECTOR | 2 | |
| 1488347 | 38 ELBOW AS | 4 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9007 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 6V9160 | 39 TEE-FACE SEAL | 2 | |
| 6V9746 | 40 SEAL-O-RING | 8 | |
| 7X0909 | 41 BOLT (M12X1.75X140-MM) | 2 | |
| 8T0360 | 42 BOLT (M20X2.5X90-MM) | 4 | |
| 8T4139 | 43 BOLT (M12X1.75X30-MM) | 4 | |
| 8T5001 | 44 BOLT (M12X1.75X130-MM) | 2 | |
| 0322580 | 45 SCREW-TAPPING (1/4-20X1-IN) | 3 | |
| 4479741 | KIT-SEAL (COUPLING) | 1 |
