System And Components
4W-5773 LINES GP-AFTERCOOLER AIRS/N CTM1-UP
Group No: 4W-5773
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3307151 | 1 HOSE AS | 1 | |
| 2W7962 | 2 PIPE | 1 | |
| 0321267 | 3 CONNECTOR (STRAIGHT) | 1 | |
| 8T6765 | 4 PLUG-PIPE (1/4-18-THD) | 1 | |
| 0321268 | 5 CONNECTOR (90-DEG) | 1 | |
| 7L4302 | 6 GASKET | 2 | |
| 2W7111 | 7 FLANGE | 2 | |
| 4W3851 | 8 BRACKET | 2 | |
| 6V2695 | 9 SEAL-O-RING | 4 | |
| 5P5700 | 10 SEAL-O-RING | 4 | |
| 4W9725 | 13 GASKET | 1 | |
| 4W9726 | 14 FLANGE | 1 | |
| 7B3235 | 15 BOLT (1/2-13X1.375-IN) | 6 | |
| 1A5822 | 16 BOLT (1/2-13X2.75-IN) | 2 | |
| 9S1366 | 17 BOLT (1/2-13X2.5-IN) | 6 | |
| 1A2029 | 18 BOLT (3/8-16X1.125-IN) | 1 | |
| 5P8245 | 19 WASHER-HARD (13.5X25.5X3-MM THK) | 14 | |
| 9X6458 | 20 WASHER-HARD (10.2X22.5X3-MM THK) | 2 | |
| 5N4432 | 21 BOOT | 2 | |
| 5P3860 | 22 CLAMP-HOSE | 2 | |
| 2W7961 | 23 PIPE | 1 | |
| 8T1889 | 24 CLIP (SLOT) | 1 | |
| 8T1890 | 25 CLIP (TAB) | 1 | |
| 6V0826 | 26 GROMMET | 1 | |
| 3B1915 | 27 BOLT (3/8-16X1.375-IN) | 1 |
