System And Components
203-9192 CYLINDER & LINES GP-FELLING HDACCUMULATOR ARM, GRAPPLE ARM
Group No: 203-9192
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1794823 | 1 PIN | 4 | |
| 1794825 | 2 PIN | 2 | |
| 1900858 | 3 CYLINDER GP-HYDRAULIC (GRAPPLE ARM) | 2 | |
| 2051819 | 4 PIN | 2 | |
| 2051822 | 5 LINES GP-FELLING HEAD CYLINDER | 1 | |
| 0964885 | 6 LOCKNUT (M16X2-THD) | 8 | |
| 8T4174 | 7 BOLT (M16X2X120-MM) | 8 | |
| 9X8257 | 8 WASHER (17.5X30X3.5-MM THK) | 8 | |
| 1900858 | 9 CYLINDER GP-HYDRAULIC (ACCUMULATOR ARM) | 2 |
