System And Components
337-5525 ARM GP-ACCUMULATORPART OF 508-1885 HEAD AR-HARVESTER
Group No: 337-5525
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1205737 | 1 WASHER (17.5X40X4-MM THK) | 3 | |
| 3306045 | 2 CYLINDER GP-HYDRAULIC | 1 | |
| 3316249 | 3 PIN | 1 | |
| 3316250 | 4 PIN | 1 | |
| 3316251 | 5 PIN | 2 | |
| 3346901 | 6 PIN AS | 1 | |
| 3346903 | 7 PIN AS | 1 | |
| 3362340 | 8 ARM GP-ACCUMULATOR (OUTER, LH) | 1 | |
| 2062615 | 8A BUSHING | 1 | |
| 3364203 | 9 ARM AS-INNER | 1 | |
| 3352347 | 9A BEARING | 2 | |
| 3376530 | BOSS | 1 | |
| 3365855 | 10 ARM GP-ACCUMULATOR (INNER) | 1 | |
| 3352347 | 10A BEARING | 2 | |
| 3376530 | BOSS | 1 | |
| 3366498 | 11 LINK GP | 1 | |
| 7U9602 | 11A BEARING | 2 | |
| 3366495 | LINK | 1 | |
| 3367428 | 12 SPACER (19.05X26.67X9.5-MM THK) | 3 | |
| 3383141 | 13 SHIM (0.06-MM THK) | 16 | |
| 3535275 | 14 ARM GP-ACCUMULATOR (OUTER, RH) | 1 | |
| 2062615 | 14A BUSHING | 1 | |
| 3580877 | 15 SPRING-EXTENSION | 2 | |
| 0310255 | 16 PIN-SPRING | 2 | |
| 1172195 | 17 PIN AS | 1 | |
| 2089294 | 18 BOLT-FLANGE HEAD (M10X1.5X35-MM) | 2 | |
| 1B0676 | 19 PIN | 2 | |
| 1K7077 | 20 WASHER-HARD | 4 | |
| 3B4617 | 21 PIN-COTTER | 2 | |
| 5J5731 | 22 LOCKNUT (1-3/4-12-THD) | 2 | |
| 6V3213 | 23 RING-RETAINING | 1 | |
| 6V7687 | 24 LOCKNUT (M12X1.75-THD) | 2 | |
| 7J6877 | 25 NUT (1-1/2-12-THD) | 2 | |
| 7X0537 | 26 WASHER-HARD (40.5X67X6-MM THK) | 2 | |
| 7X2554 | 27 BOLT (M16X2X70-MM) | 1 | |
| 8T0299 | 28 BOLT (M16X2X30-MM) | 3 | |
| 8T4176 | 29 BOLT (M12X1.75X90-MM) | 2 | |
| 8T4815 | 30 ROD END | 2 | |
| 8T4837 | 31 WASHER (48X85X6-MM THK) | 2 | |
| 8T5092 | 32 BOLT (M12X1.75X150-MM) | 1 | |
| 2645285 | 33 KIT-SHIM (BOOM PIVOT)(BOOM PIVOT) | 2 | |
| 3B8489 | 34 FITTING-GREASE | 9 | |
| 5F0587 | 35 SEAL-LIP TYPE | 4 |
