System And Components
439-3168 ARM GP-ACCUMULATORPART OF 508-1884 HEAD AR-FELLING
Group No: 439-3168
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2S0680 | 1 NUT (1-1/4-12-THD) | 2 | |
| 3B8489 | 2 FITTING-GREASE | 1 | |
| 6T6052 | 3 PLUG-ORIFICE | 1 | |
| 3580877 | 4 SPRING-EXTENSION | 2 | |
| 4351313 | 5 CYLINDER GP-GRAPPLE | 1 | |
| 4393109 | 6 PLATE AS | 1 | |
| 4393110 | 7 PIVOT AS | 1 | |
| 4398531 | 8 BUMPER | 1 | |
| 4398532 | 9 PIN AS | 1 | |
| 4398534 | 10 SPACER (20.63X31.8X10.4-MM THK) | 2 | |
| 4398535 | 11 PLATE | 2 | |
| 4398536 | 12 PIN | 1 | |
| 4398538 | 13 PIN AS | 1 | |
| 4398540 | 14 PIN AS | 1 | |
| 1K6872 | 15 LOCKNUT (1/2-13-THD) | 1 | |
| 3K2889 | 16 LOCKNUT (5/8-11-THD) | 1 | |
| 4L6454 | 17 BOLT (3/8-16X1-IN) | 1 | |
| 7J6877 | 18 NUT (1-1/2-12-THD) | 1 | |
| 7X0359 | 19 BOLT (5/8-11X6-IN) | 1 | |
| 7X0537 | 20 WASHER-HARD (40.5X67X6-MM THK) | 1 | |
| 8T4121 | 21 WASHER-HARD (11X21X2.5-MM THK) | 1 | |
| 8T4122 | 22 WASHER-HARD (17X32X3.5-MM THK) | 2 | |
| 8T8920 | 23 BOLT (1/2-13X3.25-IN) | 1 |
