System And Components
152-8026 CONTROL AR-DASA ELECTRONIC -380 ENGLISHType 2
Group No: 152-8026
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1698348 | 1 SOFTWARE GP-IMPLEMENT (DASA) | 1 | |
| 1698939 | 2 CONTROL GP-IMPLEMENT (HARVESTER HEAD) | 1 | |
| 1615224 | 3 CABLE (PRINTER) | 1 | |
| 1859337 | 4 HARNESS AS-CONSOLE | 1 | |
| 1028804 | KIT-RECEPTACLE (4-PIN) | 1 | |
| 1028801 | KIT-RECEPTACLE (12-PIN) | 1 | |
| 8T8737 | PLUG-SEAL | 16 | |
| 1552274 | KIT-CONNECTING PLUG (6-PIN) | 1 | |
| 1921632 | 5 HARNESS AS-CONSOLE | 1 | |
| 1028805 | KIT-RECEPTACLE (6-PIN) | 1 | |
| 1733863 | 6 CABLE | 1 | |
| 1615213 | 7 KEYPAD AS | 2 | |
| 1671828 | SWITCH-KEYPAD | 10 | |
| 6V2858 | 8 GROMMET | 2 | |
| 1730109 | 9 FILM-INSTRUCTION (PALLET, LH) | 1 | |
| 1730108 | 10 FILM-INSTRUCTION (PALLET, RH) | 1 | |
| 1615212 | 11 BAR (KEYPADS) | 2 | |
| 1615218 | 12 BRACKET (KEYPAD) | 4 | |
| 5C2890 | 13 NUT (M6X1-THD) | 6 | |
| 1615214 | 14 BOX (POTENTIOMETER) | 1 | |
| 1615221 | 15 SUPPORT | 1 | |
| 1615225 | 16 PRINTER GP-COMPUTER | 1 | |
| 1922844 | 17 HARNESS AS-CONSOLE | 1 | |
| 9X1339 | RECEPTACLE AS-CONNECTOR (40-PIN) | 1 | |
| 9X7147 | PLUG AS-CONNECTOR (40-PIN) | 1 | |
| 3E4367 | RING-RETAINING | 1 | |
| 3E8557 | BOLT (M5X0.8X39.37-MM) | 1 | |
| 9X3490 | SEAL-CONNECTOR (40-PIN) | 2 | |
| 1552271 | KIT-CONNECTING PLUG (4-PIN) | 1 | |
| 7X2533 | 18 BOLT (M6X1X35-MM) | 4 | |
| 8T4971 | 19 BOLT (M6X1X30-MM) | 2 | |
| 6V9673 | 20 SCREW-MACHINE (M5X0.8X12-MM) | 3 | |
| 1705632 | 21 BOLT (M4X0.7X16-MM) | 4 | |
| 1682156 | 22 COVER | 1 | |
| 1682152 | 23 HANDLE | 2 | |
| 1682150 | 24 SPACER | 2 | |
| 1682151 | 25 ROD | 2 | |
| 1744469 | 26 SEAL (1.0 M) | ||
| 7X7739 | 27 WASHER (9.7X25.4 X4-MM THK) | 4 | |
| 1941972 | 28 CLAMP | 2 | |
| 1941974 | 29 PLATE | 2 | |
| 1941976 | 30 PLATE AS | 1 |
