System And Components
Assembly
100%

196-1279 CONTROL GP-ELECTRONICCABSWIN

Group No: 196-1279
Part NumberPart NameQty
22100921 BOX-CONTROL (CU)1
22100962 BOX-CONTROL (ANALOG OUTPUT)(A)1
22100973 BOX-CONTROL (ANALOG INPUT)(I)1
19705114 HARNESS AS-MONITOR (CONTROL UNIT)1
19705125 HARNESS AS-MONITOR (ANALOG OUTPUT BOX)1
19705156 HARNESS AS-SENSOR (SAW HOME)1
19705167 HARNESS AS-SENSOR (SAW POSITION)1
19705188 HARNESS AS-WIRING (FEED ROLLER MOTOR, LH)1
19705199 HARNESS AS-WIRING (FEED ROLLER MOTOR, RH)1
197052010 HARNESS AS-WIRING (DELIMBING KNIFE OPEN, CLOSE)1
197052111 HARNESS AS-WIRING (HOLDING ARM OPEN, CLOSE)1
197052212 HARNESS AS-CONTROL (CUT SYSTEM ON, OFF)1
197052313 HARNESS AS-WIRING (ROLLER ARM OPEN, CLOSE)1
197052414 HARNESS AS-WIRING (TILT UP, DOWN)1
198615515 CAP12
3S2093STRAP-CABLE
