System And Components
257-0197 BLADE & MOUNTING GPS/N BCZ2001-99999
Group No: 257-0197
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2756279 | 1 PIPE | 2 | |
| 5W2731 | 2 LOCK PIN | 2 | |
| 5W2817 | 3 FITTING-GREASE (HYDRAULIC) | 8 | |
| 5W4223 | 4 COVER | 2 | |
| 8U3528 | 5 HINGE AS | 2 | |
| 8U3537 | 6 BUMPER-RUBBER (RUBBER) | 2 | |
| 0930349 | 7 WASHER (22X60X6-MM THK) | 8 | |
| 1092092 | 8 BRACKET AS | 1 | |
| 1092947 | 9 LINKAGE AS | 1 | |
| 1102158 | 10 PIN AS | 2 | |
| 1102159 | 11 PIN AS | 2 | |
| 1179893 | 12 SLEEVE | 2 | |
| 1179896 | 13 SLEEVE | 6 | |
| 1266760 | 14 BLADE AS-BULLDOZER | 1 | |
| 1316454 | 15 SCREW-FLAT HEAD (M8X1.25X25-MM) | 4 | |
| 1967156 | 16 GUARD AS | 1 | |
| 2577755 | 17 PIN AS | 2 | |
| 2577756 | 18 PIN AS | 2 | |
| 5C7261 | 19 NUT (M8X1.25-THD) | 4 | |
| 5P4116 | 20 WASHER-HARD (8.8X20.5X2-MM THK) | 4 | |
| 6V8202 | 21 BOLT-SOCKET HEAD (M8X1.25X16-MM) | 4 | |
| 6V8212 | 22 BOLT (M10X1.5X16-MM) | 4 | |
| 8T4123 | 23 WASHER (22X35X3.5-MM THK) | 12 | |
| 8T4224 | 24 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 8T4780 | 25 BOLT (M20X2.5X30-MM) | 8 |
