System And Components
321-8730 DOOR GP-ACCESS -AIR CLEANER, BATTERYS/N W8R5000-UP
Group No: 321-8730
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1007740 | 1 RING-RETAINING | 2 | |
| 2034464 | 2 MOUNT-RESILIENT | 1 | |
| 2159415 | 3 PIN | 2 | |
| 2592355 | 4 HINGE AS | 2 | |
| 2592385 | 5 SPRING-GAS | 1 | |
| 3623495 | 6 LATCH AS-HANDLE | 1 | |
| 2900294 | 7 COVER | 1 | |
| 2961858 | 8 PLATE | 1 | |
| 3218729 | 9 DOOR AS | 1 | |
| 1965693 | HINGE AS | 2 | |
| 1293178 | 10 LOCKNUT (M6X1-THD) | 1 | |
| 5C2890 | 11 NUT (M6X1-THD) | 7 | |
| 5C7261 | 12 NUT (M8X1.25-THD) | 3 | |
| 5P4116 | 13 WASHER-HARD (8.8X20.5X2-MM THK) | 6 | |
| 6V7357 | 14 BOLT (M6X1X25-MM) | 1 | |
| 8T4138 | 15 BOLT (M6X1X20-MM) | 1 | |
| 8T4189 | 16 BOLT (M8X1.25X20-MM) | 3 | |
| 9X8256 | 17 WASHER (6.6X12X2-MM THK) | 4 |
