System And Components
250-9606 STEERING GP-HYDRAULICS/N W8R1-5082
Group No: 250-9606
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1253249 | 1 NUT-SPEED | 6 | |
| 1957873 | 2 BRACKET | 1 | |
| 2276007 | 3 STEERING WHEEL AS | 1 | |
| 2276009 | 4 KNOB AS-STEERING | 1 | |
| 2412489 | 5 CAP (COVER) | 1 | |
| 2434051 | 6 COVER AS | 1 | |
| 2434052 | 7 COVER | 1 | |
| 2434053 | 8 COVER | 1 | |
| 2780964 | 9 BRACKET AS | 2 | |
| 2781534 | 10 STEERING COLUMN GP | 1 | |
| 2820591 | 11 CLAMP-BAND | 2 | |
| 2975131 | 12 SWITCH AS-MULTIFUNCTION | 1 | |
| 8T8737 | PLUG-SEAL | 1 | |
| 1519275 | KIT-RECEPTACLE (6-PIN) | 1 | |
| 1603518 | KIT-RECEPTACLE (8-PIN) | 1 | |
| 1863735 | PIN-CONNECTOR (16-GA TO 18-GA) | 13 | |
| 0960061 | 13 STRAP-CABLE | 1 | |
| 0992374 | 14 BOLT-SOCKET HEAD (M5X0.8X12-MM) | 2 | |
| 1256083 | 15 SCREW-PAN HEAD | 6 | |
| 6V8227 | 16 NUT (M18X1.5-THD) | 1 | |
| 7Y7388 | 17 SCREW-BUTTON HEAD (M5X0.8X12-MM) | 2 | |
| 8T4121 | 18 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4136 | 19 BOLT (M10X1.5X25-MM) | 4 |
