System And Components
188-4991 CYLINDER GP-STABILIZERS/N D8W1-UP
Group No: 188-4991
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2000916 | 1 CYLINDER AS | 1 | |
| 2000917 | 2 ROD | 1 | |
| 2000918 | 3 PISTON | 1 | |
| 2000919 | 4 COLLAR | 1 | |
| 2213539 | 5 PISTON | 1 | |
| 1183116 | 6 RETAINER | 2 | |
| 1183117 | 7 CONE | 2 | |
| 5W1274 | 8 PLUG | 2 | |
| 2258698 | 9 SEAL | 1 | |
| 1182716 | 10 RING | 1 | |
| 1182717 | 11 RING | 2 | |
| 1357933 | 12 SEAL-O-RING | 1 | |
| 1357934 | 13 RING-BACKUP | 1 | |
| 1357935 | 14 SEAL-O-RING | 1 | |
| 1357936 | 15 RING | 1 | |
| 1357937 | 16 SEAL-O-RING | 1 | |
| 1357938 | 17 RING-BACKUP | 1 | |
| 1357939 | 18 RING | 1 | |
| 5W6388 | 19 SEAL-O-RING | 1 | |
| 1182727 | 20 RING-BACKUP | 1 | |
| 4J5351 | 21 SEAL-O-RING | 3 | |
| 1183130 | 22 RING-BACKUP | 2 | |
| 1183131 | 23 SEAL-O-RING | 2 | |
| 1183132 | 24 SPRING | 2 | |
| 1182730 | 25 NUT (M52X1.5-THD, LH) | 1 | |
| 1182731 | 26 PIN | 1 | |
| 8G4189 | 27 BEARING-SELF-ALIGNING | 2 | |
| 8T0707 | 28 RING-RETAINING (INTERNAL) | 4 | |
| 1182732 | 29 FITTING-GREASE | 1 | |
| 2213541 | 30 RING-BACKUP | 2 | |
| 2000920 | KIT-SEAL (STABILIZER CYLINDER) | 1 |
