System And Components
435-6506 LINES GP-CHECK VALVE -1-PIECE BOOM, STICK CYLINDERS/N F2W1-524
Group No: 435-6506
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4I9521 | 1 BAND-MARKER (RED, L1) | 2 | |
| 5W9857 | 2 FLANGE-HALF | 2 | |
| 7K1181 | 3 STRAP-CABLE | 11 | |
| 1130435 | 4 HOSE AS | 1 | |
| 1167286 | 5 CLAMP-SINGLE | 1 | |
| 1254906 | 6 HOSE AS | 1 | |
| 1335813 | 7 BAND-MARKER (GRAY, P) | 2 | |
| 1518865 | 8 ELBOW | 1 | |
| 1856798 | 9 HOSE AS | 1 | |
| 1856799 | 10 HOSE AS | 1 | |
| 1875076 | 11 CLAMP AS | 1 | |
| 2635618 | 12 CLAMP AS (SINGLE) | 6 | |
| 2635132 | CLAMP | 2 | |
| 2635133 | GROMMET | 2 | |
| 2636333 | 13 CLAMP GP-HYDRAULIC LINES | 3 | |
| 2635129 | CLAMP-TWIN | 2 | |
| 2636335 | GROMMET | 2 | |
| 2636336 | GROMMET | 2 | |
| 2637038 | 14 CLAMP GP-HYDRAULIC LINES | 6 | |
| 2635132 | CLAMP | 2 | |
| 2636337 | GROMMET | 2 | |
| 3292352 | 15 TUBE AS | 1 | |
| 3292353 | 16 TUBE AS | 1 | |
| 3292382 | 17 TUBE AS | 1 | |
| 3292383 | 18 TUBE AS | 1 | |
| 3403050 | 19 CLAMP GP-HYDRAULIC LINES | 1 | |
| 1949389 | PLATE | 1 | |
| 3403049 | CLAMP | 2 | |
| 3403060 | 20 TUBE AS | 1 | |
| 3648088 | 21 VALVE GP-CHECK (PILOT OPERATED) | 1 | |
| 4J5267 | SEAL-O-RING | 1 | |
| 3861188 | 22 VALVE GP-SHUTTLE (STICK CYLINDER)(STICK CYLINDER) | 1 | |
| 3E4298 | SEAL-O-RING | 1 | |
| 1017398 | 23 BOLT-SOCKET HEAD (M10X1.5X40-MM) | 8 | |
| 1017404 | 24 BOLT-SOCKET HEAD (M10X1.5X30-MM) | 30 | |
| 1053478 | 25 BOLT-SOCKET HEAD (M10X1.5X35-MM) | 6 | |
| 1488336 | 26 CONNECTOR AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 1488378 | 27 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8724 | ELBOW | 1 | |
| 1495452 | 28 UNION AS (STRAIGHT) | 2 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V8994 | UNION (STRAIGHT) | 1 | |
| 4J5267 | 29 SEAL-O-RING | 2 | |
| 5K9090 | 30 SEAL-O-RING | 5 | |
| 5P7466 | 31 CLIP (SLOT) | 1 | |
| 5P7467 | 32 CLIP (TAB) | 1 | |
| 5P7468 | 33 CLIP (SLOT) | 1 | |
| 5P7469 | 34 CLIP (TAB) | 1 | |
| 5P8112 | 35 GROMMET | 1 | |
| 5P8444 | 36 GROMMET (37-MM ID) | 1 | |
| 6V8367 | 37 LOCKWASHER | 4 | |
| 6V9168 | 38 NUT (11/16-16-THD) | 2 | |
| 6V9746 | 39 SEAL-O-RING | 5 | |
| 7X2533 | 40 BOLT (M6X1X35-MM) | 2 | |
| 7X7729 | 41 WASHER (11X25X3-MM THK) | 2 | |
| 1856804 | 42 HOSE AS | 2 | |
| 1856805 | 43 HOSE AS | 2 | |
| 4521549 | 44 HOSE AS | 2 |
