System And Components
310-3130 DOOR GP-ACCESS -ENGINES/N EN91-UP
Group No: 310-3130
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1166325 | 1 SPRING-GAS | 2 | |
| 2063623 | 3 HANDLE AS | 1 | |
| 2069348 | 4 LATCH AS | 1 | |
| 2549404 | 5 SUPPORT AS | 1 | |
| 2549409 | 6 DOOR AS-ACCESS | 1 | |
| 2549405 | 6A HINGE AS | 2 | |
| 2566420 | 7 INSULATION | 1 | |
| 3623495 | 8 LATCH AS-HANDLE | 1 | |
| 2786964 | 9 SPRING-GAS | 1 | |
| 3053606 | 10 COVER AS | 1 | |
| 2549405 | 10A HINGE AS | 2 | |
| 3053615 | 11 ROD | 1 | |
| 1313539 | 12 SCREW-FLAT HEAD (M8X1.25X30-MM) | 2 | |
| 1593046 | 13 BOLT (M8X1.25X20-MM) | 4 | |
| 2442422 | 14 INSULATION | 1 | |
| 5C2874 | 15 NUT (M5X0.8-THD) | 1 | |
| 5C2890 | 16 NUT (M6X1-THD) | 4 | |
| 5C7261 | 17 NUT (M8X1.25-THD) | 5 | |
| 5P4116 | 18 WASHER-HARD (8.8X20.5X2-MM THK) | 8 | |
| 8T4171 | 19 BOLT (M6X1X12-MM) | 2 | |
| 8T4189 | 20 BOLT (M8X1.25X20-MM) | 4 | |
| 8T4224 | 21 WASHER-HARD (8.8X16X2-MM THK) | 5 | |
| 9X8256 | 22 WASHER (6.6X12X2-MM THK) | 6 | |
| 1265648 | 23 SEAL (69-CM) | ||
| 3103137 | 24 SEAL (191-CM) |
