Assembly
100%

325-0726 JAW GP-COMBINATIONS/N JMY1-UP

Group No: 325-0726
Part NumberPart NameQty
16903851 EDGE-CUTTING1
16903862 SHIM (1-MM THK)4
16903883 SHIM (1.5-MM THK)1
16971174 EDGE-CUTTING4
16971185 SHIM (1-MM THK)12
16971196 SHIM (1.5-MM THK)4
17237227 PIN1
17237238 BUSHING2
17237249 SPACER (180X194X42-MM THK)1
172372510 SHIM (2.5-MM THK)2
172372611 SHIM (3-MM THK)2
172372712 SHIM (3.5-MM THK)2
280920013 TOOTH3
325072714 JAW AS (LOWER)1
317089414A PLATE-WEAR2
325072815 JAW AS (UPPER)1
317357315A PLATE-WEAR1
144271516 SCREW-FLAT HEAD (M20X2.5X100-MM)9
159112217 LOCKWASHER3
170352418 SCREW-FLAT HEAD (M20X2.5X80-MM)6
6V820019 BOLT-SOCKET HEAD (M12X1.75X35-MM)6
7X257520 BOLT (M24X3X60-MM)2
8T036321 BOLT (M24X3X120-MM)3
8T400122 NUT (M24X3-THD)5
8T412323 WASHER (22X35X3.5-MM THK)15
8T413124 NUT (M20X2.5-THD)15
347250325 HOLDER-TOOTH1
347250226 HOLDER-TOOTH1
