System And Components
267-6796 DRIVE GP-FINAL -WITHOUT MOTORPART OF 267-6877 DRIVE GP-FINAL
Group No: 267-6796 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3E2338 | 1 PLUG-PIPE | 2 | |
| 2676863 | 2 SHIM (0.75-MM THK) | 1 | |
| 7Y0752 | SHIM (0.8-MM THK) | 1 | |
| 2676864 | SHIM (0.85-MM THK) | 1 | |
| 2676865 | SHIM (0.9-MM THK) | 1 | |
| 2676866 | SHIM (0.95-MM THK) | 1 | |
| 7Y0753 | SHIM (1-MM THK) | 1 | |
| 2676867 | SHIM (1.2-MM THK) | 1 | |
| 2676868 | SHIM (1.4-MM THK) | 1 | |
| 7Y0754 | SHIM (1.6-MM THK) | 1 | |
| 2676869 | SHIM (1.8-MM THK) | 1 | |
| 2676870 | SHIM (2-MM THK) | 1 | |
| 2676871 | SHIM (2.3-MM THK) | 1 | |
| 0940578 | 5 PLATE (8-MM THK) | 1 | |
| 0940579 | PLATE (9-MM THK) | 1 | |
| 0940580 | PLATE (10-MM THK) | 1 | |
| 0941528 | 8 WASHER (53X84X1-MM THK) | 12 | |
| 1141540 | 9 PIN-DOWEL | 4 | |
| 1688452 | 10 BALL BEARING | 2 | |
| 1695589 | 11 GEAR-SUN (24-TEETH) | 1 | |
| 1695590 | 12 GEAR-SUN (24-TEETH) | 1 | |
| 1695592 | 13 GEAR-PLANETARY (23-TEETH) | 3 | |
| 1695593 | 14 GEAR-PLANETARY (23-TEETH) | 3 | |
| 1695601 | 15 SHAFT-PLANETARY | 3 | |
| 1695602 | 16 SHAFT-PLANETARY | 3 | |
| 1719387 | 17 GEAR-RING (64-TEETH) | 1 | |
| 1912569 | 18 BEARING AS (CAGED ROLLER) | 3 | |
| 1912570 | 19 BEARING AS (CAGED ROLLER) | 6 | |
| 1912571 | 20 CARRIER-PLANETARY | 1 | |
| 1912676 | 21 GEAR-RING (72-TEETH) | 1 | |
| 1912683 | 22 GEAR-SUN (20-TEETH) | 1 | |
| 1912684 | 23 GEAR-PLANETARY (21-TEETH) | 3 | |
| 1912685 | 24 BEARING AS | 3 | |
| 1912686 | 25 CARRIER AS | 1 | |
| 1912687 | RACE-BEARING | 3 | |
| 1912689 | 26 WASHER (34X70X1-MM THK) | 3 | |
| 1912690 | 27 WASHER (42.3X70X1-MM THK) | 3 | |
| 1994503 | 28 COVER | 1 | |
| 2071571 | 29 SEAL GP-DUO-CONE | 1 | |
| 2143570 | RING-TORIC | 2 | |
| 2676797 | 30 HOUSING-MOTOR | 1 | |
| 2676798 | 31 HOUSING | 1 | |
| 2676799 | 32 CARRIER-PLANETARY | 1 | |
| 2676800 | 33 GEAR-COUPLING | 1 | |
| 0931731 | 43 RING-RETAINING | 2 | |
| 0950891 | 44 PIN-SPRING | 6 | |
| 0960433 | 45 RING-RETAINING | 3 | |
| 0963216 | 46 SETSCREW-SOCKET (M12X1.75X12-MM) | 2 | |
| 1719298 | 47 SEAL-O-RING | 1 | |
| 1798733 | 48 BOLT (M20X2.5X170-MM) | 16 | |
| 7M8485 | 49 SEAL-O-RING | 2 | |
| 7Y0595 | 50 SPACER (58X79.6X6-MM THK) | 3 | |
| 7Y5217 | 51 BOLT-SOCKET HEAD (M20X2.5X70-MM) | 16 | |
| 8T3282 | 52 WASHER-HARD (22X35X3.5-MM THK) | 16 | |
| 8T4123 | 53 WASHER (22X35X3.5-MM THK) | 16 | |
| 9X6032 | 54 BOLT-SOCKET HEAD (M10X1.5X30-MM) | 12 | |
| 1U8846 | 55 SEALANT-GASKET | ||
| 2676818 | KIT-FINAL DRIVE BEARING | 1 |
