448-4549 COUNTERWEIGHT GP-HYDRAULICS/N P731-UP

Group No: 448-4549
Part NumberPart NameQty
3B84891 FITTING-GREASE (1/8-27 PTF)10
9U25192 NUT (3/4-10-THD)2
50998053 PIN2
50998064 PIN2
13536245 BAR10
14897446 BAR2
50998077 PIN2
44845108 FRAME AS-COUNTERWEIGHT1
52224719 FRAME AS1
9J32069A BEARING-SPHERICAL4
5J3964RING-LOCK4
449484010 COUNTERWEIGHT AS10
453028711 LINK AS2
9R032111A BUSHING4
509980812 PIN4
456169513 ROD AS2
458313714 PIN2
264363116 BOLT (3/4-10X2.5-IN)2
313168117 ELBOW2
8T413919 BOLT (M12X1.75X30-MM)4
8T419220 BOLT (M12X1.75X25-MM)20
8T422321 WASHER-HARD (13.5X25.5X3-MM THK)24
279154022 PIN-DETENT1
522246923 PLATE AS-RETAINER1
