System And Components
432-6069 PUMP GP-CHARGES/N CB21-UP
Group No: 432-6069
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3337835 | 1 ROTATING GP-PUMP | 1 | |
| 1889640 | 2 PISTON-CONTROL | 1 | |
| 1889641 | 3 GUIDE-CONTROL | 1 | |
| 1051634 | 4 PLUNGER | 1 | |
| 1051636 | 5 CYLINDER-CONTROL | 1 | |
| 1051635 | 6 SPRING | 1 | |
| 1437052 | 7 SLEEVE-STOP | 1 | |
| 1051633 | 8 HOUSING-PUMP | 1 | |
| 4923851 | 9 HEAD | 1 | |
| 3019279 | 10 SWASHPLATE AS | 1 | |
| 1946847 | 11 SHAFT | 1 | |
| 3738465 | 12 COUPLER | 1 | |
| 1051638 | 13 SPACER (30X38X3-MM THK) | 1 | |
| 3B2263 | 14 CUP-BEARING | 1 | |
| 1053031 | 15 CONE-BEARING | 1 | |
| 1053032 | 16 CONE-BEARING | 1 | |
| 1053033 | 17 CUP-BEARING | 1 | |
| 1051642 | 18 BEARING | 2 | |
| 7X1553 | 19 SEAL-LIP TYPE | 1 | |
| 1629997 | 20 SEAL-O-RING | 1 | |
| 8U5951 | 21 SEAL-O-RING | 4 | |
| 1357935 | 22 SEAL-O-RING | 1 | |
| 1401739 | 23 RING-RETAINING | 1 | |
| 6V8201 | 24 BOLT-SOCKET HEAD (M16X2X45-MM) | 4 | |
| 9S4183 | 25 PLUG (1-1/16-12-THD) | 1 | |
| 3D2824 | 26 SEAL-O-RING | 1 | |
| 1281929 | 27 PIN-DOWEL | 1 | |
| 3337848 | 28 VALVE GP-PUMP CONTROL | 1 | |
| 8T8442 | 28A BOLT-SOCKET HEAD (M6X1X30-MM) | 4 | |
| 2807870 | 28B GASKET | 1 |
