Assembly
100%

419-7065 COUNTERWEIGHT GPS/N ZAC1-UP

Group No: 419-7065
Part NumberPart NameQty
3B84891 FITTING-GREASE (1/8-27 PTF)10
9U25192 NUT (3/4-10-THD)2
50998053 PIN2
13481544 PIN2
50998065 PIN2
13536246 BAR8
14897447 BAR4
52691168 FRAME AS (COUNTERWEIGHT)1
52224739 FRAME AS1
9J32069A BEARING-SPHERICAL4
5J3964RING-LOCK4
437213510 LINK AS2
9R032110A BUSHING4
509980711 PIN6
456169112 ROD AS2
264363114 BOLT (3/4-10X2.5-IN)2
4M897315 ELBOW2
5P222816 BOLT (1/2-13X1-IN)4
8T419217 BOLT (M12X1.75X25-MM)20
8T422318 WASHER-HARD (13.5X25.5X3-MM THK)24
279154019 PIN-DETENT1
518171520 PLATE AS1
542473221 COUNTERWEIGHT AS1
4599038COUNTERWEIGHT AS2
542473322 COUNTERWEIGHT GP3
5424715COUNTERWEIGHT AS4
