System And Components
131-3487 PUMP & LINES GP-WATER SPRAYS/N 5ZS1-UP
Group No: 131-3487
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1L2279 | 1 ELBOW | 2 | |
| 3B7722 | 2 BUSHING-PIPE | 1 | |
| 3B7731 | 3 ELBOW | 1 | |
| 5D1026 | 4 CLAMP-BAND | 2 | |
| 6R3902 | 5 HOSE AS | 1 | |
| 7R4183 | 6 GAUGE-WATER PRESSURE | 1 | |
| 8C6867 | 7 CONNECTOR | 3 | |
| 8L6005 | 8 TEE-PIPE | 1 | |
| 9N3666 | 9 VALVE-MANUAL | 1 | |
| 0032143 | 10 ELBOW | 1 | |
| 0046683 | 11 FITTING | 1 | |
| 0319746 | 12 ELBOW | 1 | |
| 1162001 | 13 STRAINER GP-WATER | 1 | |
| 1324861 | 14 PUMP & MOTOR GP-WATER SPRAY | 1 | |
| 0039514 | 15 COUPLING-PIPE | 2 | |
| 0308370 | 16 ADAPTER-PIPE | 1 | |
| 3B7255 | 17 BUSHING-REDUCER | 1 | |
| 3B7744 | 18 FITTING | 1 | |
| 3J1907 | 19 SEAL-O-RING | 1 | |
| 4J5477 | 20 SEAL-O-RING | 3 | |
| 5C7261 | 21 NUT (M8X1.25-THD) | 3 | |
| 8T4224 | 22 WASHER-HARD (8.8X16X2-MM THK) | 6 | |
| 8T4908 | 23 BOLT (M8X1.25X25-MM) | 3 | |
| 9S4191 | 24 PLUG (9/16-18-THD) | 1 | |
| 9U7015 | 25 FITTING | 2 | |
| 5P0765 | 26 HOSE (58CM) |
