System And Components
1G-8385 LINES GP-WATER SPRAYS/N 8GS256-UP
Group No: 1G-8385
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2492942 | 1 ADAPTER | 1 | |
| 0822835 | 2 VALVE | 1 | |
| 9Y6977 | 3 CLAMP | 2 | |
| 0818623 | 4 FITTING | 1 | |
| 0821065 | 5 FITTING | 2 | |
| 0821057 | 6 ELBOW | 1 | |
| 5P0598 | 7 CLAMP-HOSE | 8 | |
| 4L6454 | 8 BOLT (3/8-16X1-IN) | 4 | |
| 8T4896 | 9 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 0817008 | 10 FITTING | 2 | |
| 0821058 | 11 FITTING | 1 | |
| 1G9640 | 12 HOSE-WATER (181-CM) | ||
| 1G9640 | 12A HOSE-WATER (160-CM) | ||
| 6R3284 | 13 CLAMP-HALF | 4 | |
| 0869078 | 14 PLATE | 2 | |
| 7X0336 | 15 BOLT (1/2-13X5.5-IN) | 4 | |
| 8T4223 | 16 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 0869625 | 17 ELBOW-PIPE | 3 |
