System And Components
472-2960 INSTALLATION GP-COMMUNICATION -PL631S/N JFC1-UP
Group No: 472-2960
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8C5607 | 1 MOUNT-ISOLATION | 8 | |
| 8T8737 | 2 PLUG-SEAL | 8 | |
| 1772215 | 3 STRAP-DUAL CLAMP | 3 | |
| 2006345 | 4 SADDLE-MOUNTING (DUAL SWIVEL) | 1 | |
| 2042281 | 5 STRAP-CABLE | 2 | |
| 3538773 | 6 CABLE AS-COAXIAL | 1 | |
| 4174722 | 7 CONTROL GP-COMMUNICATION (NETWORK MANAGER) | 1 | |
| 4427199 | 8 CONTROL GP-UNPROGRAMMED (PRODUCT LINK ELITE 631 SATELLITE) | 1 | |
| 4438462 | 9 ANTENNA AS (CELLULAR) | 1 | |
| 3611045 | NUT-SPECIAL (5/8-18-THD) | 1 | |
| 3858201 | CAP AS-CONNECTOR | 1 | |
| 4722527 | 10 HARNESS AS-CONTROL | 1 | |
| 4750239 | 11 BRACKET AS | 1 | |
| 9X8256 | 12 WASHER (6.6X12X2-MM THK) | 7 | |
| 9X6165 | 13 WASHER (6.5X22X2.5-MM THK) | 4 | |
| 1552264 | 14 PLUG AS-CONNECTOR | 1 | |
| 1566175 | 15 CLIP (LADDER) | 1 | |
| 3523968 | 16 CLIP (LADDER) | 1 | |
| 4P7581 | 17 CLIP (LADDER) | 3 | |
| 5C7261 | 18 NUT (M8X1.25-THD) | 2 | |
| 5C9553 | 19 BOLT (M6X1X16-MM) | 3 | |
| 5P8439 | 20 GROMMET | 1 | |
| 6V7357 | 21 BOLT (M6X1X25-MM) | 4 | |
| 7K1181 | 22 STRAP-CABLE | 14 | |
| 7X2533 | 23 BOLT (M6X1X35-MM) | 4 | |
| 8C5608 | 24 SPACER (6.5X9.5X25.4-MM THK) | 4 | |
| 8T4224 | 25 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 8T4908 | 26 BOLT (M8X1.25X25-MM) | 2 | |
| 5128658 | SOFTWARE GP-MONITOR (SATELLITE RADIO) | 1 | |
| 5128631 | SOFTWARE GP-MONITOR (NETWORK MANAGER) | 1 |
