System And Components
480-8705 AIR CLEANER & MOUNTING GPS/N KT41-UP
Group No: 480-8705
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T4182 | 1 BOLT (M10X1.5X45-MM) | 1 | |
| 8T4196 | 2 BOLT (M10X1.5X35-MM) | 2 | |
| 8T4908 | 3 BOLT (M8X1.25X25-MM) | 4 | |
| 7X7729 | 4 WASHER (11X25X3-MM THK) | 4 | |
| 8T4224 | 5 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 8U6668 | 6 VALVE | 1 | |
| 9N0720 | 7 ELBOW-AIR INLET | 2 | |
| 2410566 | 8 HOSE | 1 | |
| 3445675 | 9 NUT (M10X1.5-THD) | 1 | |
| 4883461 | 10 AIR CLEANER GP | 1 | |
| 1165763 | CLIP-SPRING | 16 | |
| 2901936 | FILTER ELEMENT AS-AIR (SECONDARY) | 1 | |
| 4883498 | FILTER ELEMENT-AIR (PRIMARY) | 1 | |
| 5069152 | COVER AS-AIR CLEANER | 1 | |
| 2901938 | LATCH | 4 | |
| 5242476 | 11 BRACKET | 1 | |
| 5242478 | 12 TUBE AS | 1 | |
| 5242479 | 13 TUBE AS | 1 | |
| 1364190 | 14 CLIP-2 PIECE | 1 | |
| 1364191 | 15 CLIP-2 PIECE | 1 | |
| 8T4988 | 16 CLAMP-HOSE | 5 | |
| 9X6654 | 17 CLAMP-HOSE | 2 |
