System And Components
482-1801 LINES GP-TURBOCHARGER AIRS/N T4F1-UP
Group No: 482-1801
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1855625 | 1 BOSS | 2 | |
| 2901993 | 2 STRAP-CABLE | 3 | |
| 3177012 | 3 CLAMP-BAND | 2 | |
| 3474867 | 4 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 3649626 | 5 ELBOW AS | 1 | |
| 2147567 | SEAL-O-RING | 1 | |
| 3649625 | ADAPTER-ELBOW | 1 | |
| 3649630 | 6 CONNECTOR AS | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3649629 | CONNECTOR | 1 | |
| 3649634 | 7 ELBOW AS | 1 | |
| 1716469 | ELBOW | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 3669293 | 8 TUBE AS (AIR) | 1 | |
| 3724482 | 9 TUBE AS-AIR | 1 | |
| 4821802 | 10 TUBE AS (AIR) | 1 | |
| 4821803 | 11 TUBE AS (AIR) | 1 | |
| 4821804 | 12 TUBE AS (AIR) | 1 | |
| 1659755 | 13 STUD (M12X1.75X70-MM)(BOLT) | 3 | |
| 1A5350 | 14 CLIP | 1 | |
| 2815838 | 15 ELBOW | 1 | |
| 3422134 | 16 CLIP (LOOP) | 2 | |
| 3630253 | 17 CLIP (TAB) | 4 | |
| 3630254 | 18 CLIP (SLOT) | 4 | |
| 3H7654 | 19 WASHER-HARD (13.5X22.5X3-MM THK) | 1 | |
| 5P7970 | 20 NUT (M8X1.25-THD) | 3 | |
| 5P8245 | 21 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 6H7062 | 22 SPACER (13.5X25X19-MM THK) | 1 | |
| 6V5217 | 23 BOLT (M8X1.25X20-MM) | 1 | |
| 6V5839 | 24 WASHER (11X21X2.5-MM THK) | 2 | |
| 6V6317 | 25 BOLT (M10X1.5X20-MM) | 2 | |
| 6V8197 | 26 BOLT (M12X1.75X40-MM) | 1 | |
| 6V8837 | 27 BOLT (M6X1X16-MM) | 1 | |
| 6Y8114 | 28 SPACER (13.8X23.75X12.7-MM THK) | 1 | |
| 8K5440 | 29 CLIP | 1 | |
| 9M1974 | 30 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 9X8267 | 31 WASHER (6.6X12X2-MM THK) | 1 | |
| 3374178 | 32 HOSE (13-CM) | ||
| 3304374 | 33 SLEEVE (23-CM) |
