System And Components
481-5735 MANIFOLD GP-EXHAUSTS/N T4F1-UP
Group No: 481-5735
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9N5085 | 1 CLAMP (V-BAND) | 2 | |
| 3249290 | 2 BELLOWS AS | 1 | |
| 4815930 | 3 MANIFOLD AS-EXHAUST | 1 | |
| 2319030 | MANIFOLD-EXHAUST | 1 | |
| 4815982 | 4 MANIFOLD AS-EXHAUST | 1 | |
| 3504502 | MANIFOLD-EXHAUST | 1 | |
| 4815983 | 5 MANIFOLD AS-EXHAUST | 1 | |
| 3504503 | MANIFOLD-EXHAUST | 1 | |
| 4815984 | 6 SHIELD AS-HEAT | 1 | |
| 4815985 | 7 SHIELD AS-HEAT | 1 | |
| 4815986 | 8 SHIELD AS-HEAT | 1 | |
| 4815987 | 9 SHIELD AS-HEAT | 1 | |
| 4815988 | 10 SHIELD AS-HEAT | 1 | |
| 4815989 | 11 SHIELD AS-HEAT | 1 | |
| 4815991 | 12 SHIELD AS-HEAT | 1 | |
| 4815994 | 13 SHIELD AS-HEAT | 1 | |
| 4826002 | 14 SHIELD AS-HEAT | 1 | |
| 1163715 | 15 STUD-TAPERLOCK (M10X1.5X85-MM) | 12 | |
| 3763408 | 16 STUD-TAPERLOCK (M10X1.5X55-MM) | 4 | |
| 4P4369 | 17 SPACER (12X19X23.5-MM THK) | 12 | |
| 6V5839 | 18 WASHER (11X21X2.5-MM THK) | 12 | |
| 9X6620 | 19 LOCKNUT (M10X1.5-THD) | 12 | |
| 2832238 | 20 GASKET | 6 | |
| 3445674 | 21 NUT (M8X1.25-THD) | 1 |
