Assembly
100%

532-5104 SUPPORT GP-UNDERCARRIAGE -FRONT, LHS/N DK91-UP

Group No: 532-5104
Part NumberPart NameQty
8T41951 BOLT (M10X1.5X30-MM)2
8T41402 BOLT (M16X2X60-MM)4
3B84893 FITTING-GREASE (1/8-27 PTF)2
8T41214 WASHER-HARD (11X21X2.5-MM THK)2
9X20275 WASHER (11X18X2-MM THK)12
9X82576 WASHER (17.5X30X3.5-MM THK)4
10534787 BOLT-SOCKET HEAD (M10X1.5X35-MM)12
48240288 PLATE AS1
53250979 SUPPORT AS1
532510510 FRAME GP-FDR & TRACK ROLLER1
533321611 PIN AS2
540006412 PLATE1
