System And Components
352-9363 HOUSING GP-FLYWHEELS/N SYE1-UP
Group No: 352-9363
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2264757 | 1 SEAL GP-CRANKSHAFT (REAR) | 1 | |
| 7C1728 | SEAL-CRANKSHAFT (REAR) | 1 | |
| 1076280 | SEAL-O-RING | 1 | |
| 2717419 | 2 HOUSING AS-FLYWHEEL | 1 | |
| 4N0684 | DOWEL | 2 | |
| 8M9315 | BUSHING | 2 | |
| 2717423 | 3 COVER-GEAR | 1 | |
| 2717426 | 4 COVER-ACCESS | 2 | |
| 2733712 | 5 SEAL | 1 | |
| 3893709 | 6 PLUG AS | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 3603682 | 7 PLUG-O-RING | 1 | |
| 3893708 | 8 PLUG AS | 7 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3603679 | PLUG-CONNECTOR (9/16-18-THD) | 1 | |
| 2735039 | 9 SEAL-O-RING | 2 | |
| 2946007 | 10 BOLT-HEAD LOCKING (M6X1X18-MM) | 9 | |
| 3960393 | 11 PLUG AS | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 3603677 | PLUG (7/16-20-THD) | 1 | |
| 2A1162 | 12 GASKET | 1 | |
| 3E8016 | 13 BOLT-SELF-LOCKING (M8X1.25X25-MM) | 8 | |
| 5F0304 | 14 PLUG-DRAIN (5/8-18-THD) | 1 | |
| 5P8245 | 15 WASHER-HARD (13.5X25.5X3-MM THK) | 16 | |
| 6V3940 | 16 BOLT (M8X1.25X25-MM) | 4 | |
| 6V4248 | 17 BOLT (M10X1.5X25-MM) | 2 | |
| 6V5134 | 18 SEAL-O-RING | 1 | |
| 6V5684 | 19 BOLT (M12X1.75X45-MM) | 10 | |
| 6V5839 | 20 WASHER (11X21X2.5-MM THK) | 2 | |
| 6V8004 | 21 BOLT (M12X1.75X120-MM) | 6 | |
| 7X7730 | 22 PLUG-PIPE | 1 | |
| 9M1164 | 23 COVER | 1 | |
| 9M1974 | 24 WASHER-HARD (8.8X16X2-MM THK) | 12 | |
| 9X8267 | 25 WASHER (6.6X12X2-MM THK) | 9 | |
| 1U8846 | 26 SEALANT-GASKET |
