463-6496 DOOR GP-ACCESS -RHS/N NJ91-UP

Group No: 463-6496
Part NumberPart NameQty
8T41961 BOLT (M10X1.5X35-MM)1
8T41892 BOLT (M8X1.25X20-MM)20
8T49083 BOLT (M8X1.25X25-MM)2
5P41164 WASHER-HARD (8.8X20.5X2-MM THK)2
5T92935 LATCH-MAGNETIC2
6I05936 BOLT (M10X1.5X30-MM)1
8T03897 LOCKNUT (M10X1.5-THD)2
8T42238 WASHER-HARD (13.5X25.5X3-MM THK)3
8T42249 WASHER-HARD (8.8X16X2-MM THK)20
111177710 BUMPER-RUBBER3
222515111 PAWL1
256766912 PLATE5
286996313 LATCH AS1
305315614 PAWL2
326061015 LATCH AS2
1H3244LOCKWASHER4
0966331NUT (M12X1.75-THD)2
3260612WASHER-TAB2
3445673NUT (M6X1-THD)4
398304616 PLATE2
467884217 RETAINER1
475899018 COVER GP-REAR1
478409219 DOOR1
489822820 HINGE AS5
540390621 DOOR1
542646222 DOOR AS1
564478823 PLATE-LOCK1
