System And Components
418-4030 LINES GP-EXHAUST COMBUSTIONS/N NMA1-UP
Group No: 418-4030
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2888580 | 1 CLAMP-FUEL LINE | 6 | |
| 4882646 | 2 HOSE & TUBE AS | 1 | |
| 3757817 | 3 BRACKET AS | 1 | |
| 4882645 | 4 HOSE & TUBE AS | 1 | |
| 4182050 | 5 HOSE-MOLDED | 1 | |
| 4182051 | 6 HOSE-MOLDED | 1 | |
| 5462074 | 7 TUBE AS | 1 | |
| 0307946 | 8 ELBOW | 2 | |
| 4288808 | 9 CLAMP-HOSE | 4 | |
| 5620273 | CLAMP (CONSTANT TENSION) | 4 | |
| 1640150 | 10 SPACER (9X20X20-MM THK) | 1 | |
| 1984776 | 11 WASHER-HARD (8.8X20X8-MM THK) | 4 | |
| 8T7547 | 12 BOLT (M8X1.25X30-MM) | 4 | |
| 8T4224 | 13 WASHER-HARD (8.8X16X2-MM THK) | 5 | |
| 3320012 | 14 CLIP (LOOP) | 2 | |
| 3422135 | 15 CLIP (LOOP) | 2 | |
| 9X8256 | 16 WASHER (6.6X12X2-MM THK) | 3 | |
| 8T4971 | 17 BOLT (M6X1X30-MM) | 1 | |
| 7X2533 | 18 BOLT (M6X1X35-MM) | 1 | |
| 3441209 | 19 BOLT (M8X1.25X50-MM) | 1 | |
| 3445673 | 20 NUT (M6X1-THD) | 1 | |
| 4882647 | 21 HOSE & TUBE AS | 1 | |
| 6V9027 | 22 SEAL-O-RING | 6 | |
| 9S8002 | 23 PLUG (7/16-20-THD) | 4 |
